Clipsal Actassi LAN Cable 305m, Category 6, UTP

Home ProductsNetwork ConnectivityActassiLAN Cable

Clipsal Actassi LAN Cable 305m, Category 6, UTP | Blue

Item Number: 2D4P6IPV3B-BU

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

Titanium

Product brand

Clipsal

Colour

external sheath: blue

Physical

Communication network category

6

Awg gauge

AWG 23

Cable shielding type

UTP

Length

305 m

Ambient air temperature for operation

75 °C

Standards

  • ANSI/TIA/EIA-568-B
  • ISO/IEC 11801

Reach free of svhc

Yes

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP110217EN

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant

China rohs regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

conductor: bare copper

Others

Legacy weee scope

Out

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee applicability

Finished product

Weee label

N/A

Warranty duration(in months) bmecat

18

Cable insulation material

PVC (polyvinyl chloride)

Diameter

0.546...0.556 mm (conductor)

External diameter

6.1 mm

Flame retardance

CM

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

0.0354 cm

Package 1 width

0.0272 cm

Package 1 length

0.0344 cm

Package 1 weight

45 g

Total lifecycle carbon footprint

0.3 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

0.16274

Carbon footprint of the manufacturing phase [a1 to a3]

0.2 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

0.0072299

Carbon footprint of the distribution phase [a4]

0 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0.015364

Carbon footprint of the installation phase [a5]

0 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

0.040716

Carbon footprint of the use phase [b2, b3, b4, b6]

0 kg CO2 eq.

Sustainable packaging

No

Carbon footprint of the end-of-life phase [c1 to c4]

0.095389

Carbon footprint of the end-of-life phase [c1 to c4]

0.1 kg CO2 eq.

Pvc free

No

Halogen-free status

Product contains halogen above thresholds

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Total lifecycle carbon footprint

0.32143889999999997

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

China rohs label

1

Halogen-free status

Product contains halogen above thresholds

Pvc free

No

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
Show all specifications
