SpaceLogic C-Bus is a robust, integrated system that automates lighting and other electrical systems and products
SpaceLogic C-Bus offers scalable solutions for future buildings, providing control, comfort, efficiency, and ease of use to occupants in commercial and residential settings.
Here you’ll find links to SpaceLogic C-Bus documents and downloads, including: software, firmware, and release notes.
IMPORTANT NOTICE
For security reasons, access to C-Bus software, related documents, and other downloads is restricted to mySchneider and Club Clipsal members only.
When accessing any of the software links below you will be redirected to the relevant page.
On that page you be required to login or register.
If you have any questions or issues, please contact Customer Support.
C-Bus Software Compatibility Chart
| C‑Gate (Windows) | C‑Gate (Linux) | C‑Bus Commission | C‑Bus Toolkit | Schedule Plus | HomeGate | PICED |
|---|---|---|---|---|---|---|
| Software Versions | ||||||
| 3.7.1 | 3.7.1 | 2.14.0 | 1.19.4 | 5.12.0 | - | - |
| 3.7.0 | 3.7.0 | 2.13.0 | 1.19.3 | 5.11.0 | - | - |
| 3.6.0 | 3.6.0 | 2.12.0 | 1.19.2 | 5.10.0 | - | 4.15.4 |
| 3.5.0 | 3.5.0 | 2.10.0 | 1.19.0 ~ | 5.9.0 | - | - |
| 3.4.1 | 3.4.1 | 2.9.0 > | 1.18.1 – 1.18.2 | 5.8.0 | - | 4.15.3 |
| 3.4.0 * | 3.4.0 * | 2.7.0 # – 2.8.0 | 1.18.0 + # | 5.7.0 | - | - |
| 3.3.4 | 3.3.4 | 2.6.0 | 1.17.8 | 5.6.0 | - | - |
| 3.3.3 | 3.3.3 | 2.5.0 | 1.17.7 | 5.5.0 | - | - |
| 3.3.2 | 3.3.2 | 2.4.0 | 1.17.6 | 5.4.0 | - | - |
| 3.3.1 | 3.3.1 | 2.3.0 | 1.17.5 | 5.3.0 | - | - |
| 3.3.0 | 3.3.0 | 2.2.0 | 1.17.4 | 5.2.0 ^ | - | 4.15.2 |
| 3.2.4 | 3.2.4 | 2.1.3 | 1.17.3 | - | - | - |
| 3.2.3 | 3.2.3 | 2.1.2 | 1.17.2 | - | 4.15.1 | 4.15.1 |
| 3.2.2 | 3.2.2 | 2.1.0 | 1.17.1 | - | - | - |
| 3.2.0 | 3.2.0 | 2.0.0 | 1.17.0 | 5.1.0 | 4.15.0 | 4.15.0 |
| + Introduction of TLS 1.3 connection between C-Bus Toolkit and C-Gate 3 # Introduction of SE Software Update application ^ Introduction of maximum C-Gate 3 version restriction * C-Gate 3 switched from JRE 8 to JRE 11 > C-Bus Commission switched from .NET 6 to .NET 8 ~ C-Bus Toolkit installed into Program Files & Program Data directories | ||||||
Software & Firmware​
SpaceLogic C-Bus Commission
Next generation C-Bus commissioning software used to configure, program, and commission SpaceLogic C-Bus devices, networks and DALI-2 devices. It unlocks additional capabilities of SpaceLogic C-Bus devices (incl. profiles, sequences, temp & humidity alarms, colour temp controls & custom dimming curves).
C-Bus Toolkit
The original PC-based software used to configure, program, and commission C-Bus networks and devices. Works alongside SpaceLogic C-Bus Commission, allowing streamlined commissioning.
PICED
Programming Interface for C-Bus Embedded Devices: A Windows PC-based configuration tool for the 5500PACA controller used to design interfaces, scenes, schedules, and automation logic. Also used for C-Bus embedded devices like Touchscreens* & Wiser 2*. (*No longer available for purchase)
Schedule Plus
A Windows PC-based application for commercial and industrial C-Bus systems, offering a custom Graphical User Interface, advanced scheduling, manual control, automation, error reporting and monitoring. Ideal for commercial buildings where lighting control is not integrated into a BMS, or BMS is not available.
HomeGate
A Windows PC-based application for residential C-Bus systems, offering a custom Graphical User Interface, scheduling, manual control, monitoring and automation (including irrigation and C-Bus enabled home security Download control) that can be read on a PC or embedded PC touchscreen.
C-Bus Diagnostic Utility
A software tool for added monitoring, debugging and troubleshooting C-Bus networks by analysing traffic, device status, and communication errors.
C-Bus Software Bundle
A suite of Clipsal tools for configuring, monitoring, and managing C-Bus automation systems, including Toolkit and SpaceLogic C-Bus Commission (DOES NOT incl. HomeGate & Schedule Plus).
Controller Firmware
Firmware file for the C-Bus Controllers, 5500NAC2 & 5500AC2.
SpaceLogic C-Bus Commission
Hide ShowClick to view and/or download Quick Start Guides for:
Dimmers & Relays
Hide ShowClick to view and/or download Quick Start Guides for:
C-Bus Controllers
Hide ShowClick to view and/or download Quick Start Guides for:
C-Bus & DALI-2
Hide ShowClick to view and/or download Quick Start Guides for:
