Clipsal Wiser Lithium Battery Smoke Alarm Surface mount

Back to Smoke Alarms Home Smoke Alarms Smoke Alarms

Clipsal Wiser Lithium Battery Smoke Alarm Surface mount

Clipsal Wiser Lithium Battery Smoke Alarm Surface mount

Item Number: CLP599WSAL

The Wiser Lithium battery powered smoke alarm provides added peace of mind, combining a robust smoke alarm with smart home functions. The Wiser by SE app provides push notification alerts and Automations can trigger lights to come on if smoke is detected. New dual spectrum photoelectric sensing technology helps to mitigate false alarms for added confidence. Powered by a 10-year sealed-in lithium battery avoids the need to replace batteries.

Where To Buy

Datasheet

Download

Product Dimensions

Width icon

Width89 mm

Height icon

Height89 mm

Depth icon

Depth33.5 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-
See all

Wiser Technical Catalogue

Download Catalogue (PDF 8.2MB)
wiser smoke alarm on roof
wiser smoke alarm in bedroom
wiser smoke alarm on roof
wiser smoke alarm in bedroom

Features

  • Stylish modern multi award winning design (iF and Red Dot design awards 2022)
  • Use as a stand alone smoke alarm or as part of a Wiser smart home system.
  • New dual spectrum photoelectric smoke detection chamber to help mitigate false alarms
  • 433MHz RF and Zigbee 3.0 tech included, meaning they are compatible with Clipsal Fire Tek® Wireless smoke alarms 755LPSMA4 and 755RFB2 bases to allow simple upgrade opportunities
  • Integrate into Wiser Automations (e.g. to turn all house lights on if smoke is detected)
  • Receive push notification alerts if smoke is detected.
  • Automatic battery checking in the Wiser by SE app
  • Monthly test reminder notification option
  • Alarm history log (7 days)
  • Integrated temperature sensor will trigger alarm if temperature increases >57°for added peace of mind. (e.g. a low smoke fire or if in hush mode)
  • 10 year sealed-in non replaceable Lithium battery powered
  • Large test/hush button for simple operation
  • Slotted mounting holes for easy alignment adjustments

Specifications

Design

Range of product

Wiser

Range

Wiser

Product brand

Clipsal

Product or component type

smoke detector

Device application

early detection of smouldering fires and open fires

Colour tint

white (RAL 9003)

Sustainable offer status

Green Premium product

Physical

Type of packing

carton

Supply

battery

Communication network type

wireless Zigbee (2.4-2.4 GHz), 2.5 mW at < 50="">

Function available

  • local alarm
  • hush function
  • self-test of smoke detection

Control type

button (test/hush function)

Operating distance

  • 50 m indoor
  • 40 m indoor

Local signalling

  • visual: 1 LED (red) for warning and low battery
  • visual: 1 LED (green) for connection state
  • sound: signal (green)
  • sound: alarm

Type of installation

indoor

Device mounting

surface

Mounting support

  • ceiling
  • wall-mount

Fixing mode

by screws

Height

89 mm

Width

89 mm

Depth

33.5 mm

IP degree of protection

IP20

Ambient air temperature for operation

0...45 °C

Ambient air temperature for storage

-20...60 °C

Relative humidity

0...95 %

Product certifications

Activfire

Standards

AS 3786

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

X

Environmental Disclosure

ENVPEP2108022EN

Circularity Profile

ENVEOLI2108022EN

Material

Material

thermoplastic

Others

Package 1 Bare Product Quantity

1

Concentrator compatibility

Wiser hub generation 1

Mobile App name

Wiser by SE

Electronic sensor type

photo-electric sensor

[Us] rated supply voltage

3 V DC

Battery type

lithium 3 V

Battery life

10 year(s)

Detection type

  • heat
  • smoke

Technology type

scattered light (Tyndall effect)

Type of measurement

smoke

Number of devices

40 for wireless alarm

Noise level

85 dB at 3 m, minimum

Time delay range

10 min (hush)

Main colour tint

white

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

6.0 cm

Package 1 Width

11.5 cm

Package 1 Length

12.5 cm

Package 1 Weight

238.0 g

Unit Type of Package 2

PAL

Number of Units in Package 2

432

Package 2 Height

104.5 cm

Package 2 Width

114.0 cm

Package 2 Length

114.0 cm

Package 2 Weight

139.0 kg

Halogen content performance

Halogen free plastic parts product
Show all specifications

Frequently Asked Questions

hide show

When should I be testing my Wiser Smoke Alarm?

When installing the Wiser Smoke Alarm testing of the alarm and interconnection should be done after the product is paired to the Hub and also after any RF pairing is completed.
The Wiser Smoke Alarm is recommended to be tested monthly after installation.



Why is the power switch labeled OFF/AUTO on the Wiser Smoke Alarm?

The Power switch on the Wiser Smoke Alarm is marked OFF/AUTO because the device turns off when it is removed from it's mounting base and when reinstalled it turns on Automatically.
power switch

Can the Wiser smoke alarm interconnect with my existing alarms?

The Wiser Smoke alarm (CLP599WSAL) has 433MHz RF and Zigbee 3.0 tech included, meaning they are compatible with Clipsal Fire Tek® Wireless smoke alarms 755LPSMA4 and 755RFB2 bases to allow simple upgrade opportunities
Wiser Smoke Alarm


Can the Wiser Smoke Alarm integrate into Automations?

When used as part of a Wiser smart home system the Wiser Smoke Alarm can Integrate into Wiser Automations (e.g. to turn all house lights on if smoke is detected)
Wiser Smoke Alarm



Does Clipsal have a smart smoke alarm?

Yes, the Wiser Smart smoke alarm is a Lithium battery powered smoke alarm that gives you the ability to connect your smoke alarms as part of your smart home.

You can set automations for when the device is triggered; like turning all the lights on in the bedrooms, lighting up a path way to the front door and sending a notification to a phone so others out of the home can also take action and check on you and your home.

You can use the Wiser by SE app to check that your smoke alarms are online and working properly and that it has plenty of battery power. It can even send you test reminder notifications.

Wiser products in kitchen

Range

A Clipsal Wiser Smart Home enables you to personalise your home to fit your needs and manage it with one simple app. It’s a simple solution that can be easily integrated into any home, old or new.

All Wiser Smart Home products are also compatible with most of Clipsal’s existing wiring devices, including the Iconic switch range, making design and function upgrades simple and seamless.

With Google Home or Amazon Echo, you can also control your Clipsal Wiser Smart Home with voice commands.

With a Clipsal Wiser Smart Home, you can take control of your home the way that it suits you.
