Clipsal Resi MAX RCBO SLIM 1PN 32A C curve 30mA Type A 4500A

Clipsal Resi MAX RCBO SLIM 1PN 32A C curve 30mA Type A 4500A

Item Number: RCBE232/30S

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-
Resi MAX RCBO
Resi MAX RCBO

Specifications

Design

Range

Resi MAX

Product or component type

residual current breaker with overcurrent protection (RCBO)

Product brand

Clipsal

Device application

distribution

Market segment

residential

Physical

[in] rated current

32 A

[ue] rated operational voltage

240 V AC

Control type

ON/OFF locking with trip free mechanism

Local signalling

ON/OFF indication

Mounting mode

clip-on

Mounting support

DIN rail

Standards

AS/NZS 61009

Ip degree of protection

IP20 conforming to IEC 60529|IP40 (modular enclosure) conforming to IEC 60529

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Package 1 bare product quantity

1

Poles description

1P + N

Neutral position

left

Number of modules

1

Number of protected poles

1

Network type

AC

Trip unit technology

thermal-magnetic

Curve code

C

Earth-leakage sensitivity

30 mA

Earth-leakage protection class

type A

Breaking capacity

4.5 kA

Size

92.5 x 18 x 71.5 mm conforming to DIN 43880

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

7 cm

Package 1 width

2 cm

Package 1 length

9.8 cm

Package 1 weight

146 g

Unit type of package 2

CAR

Number of units in package 2

72

Package 2 height

30 cm

Package 2 width

30 cm

Package 2 length

40 cm

Package 2 weight

10.584 kg

Unit type of package 3

PAL

Number of units in package 3

864

Package 3 height

125 cm

Package 3 width

60 cm

Package 3 length

80 cm

Package 3 weight

127.008 kg

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

82.3706029726
Show all specifications
Resi MAX range

Circuit Protection for Australian Homes

Resi MAX is a very simple range to cover essential circuit protection needs for Australian homes. Resi MAX range helps to provide optimised solution for single phase applications with carefully chosen range of plastic enclosures, surge protection, miniature circuit breakers, isolator switch, RCDs and RCBOs.

Slim Comb busbars and accessories are also available to simplify the installation with SLIM RCBOs and help to improve installation speed by up to 10 times. Plastic enclosures in this range are optimised to provide the best balance of aesthetics, wiring space and value for money.

Products in this range are must haves for each electrician’s van as it helps to optimise installation costs without compromising on quality or performance. All Resi MAX devices provide full flexibility to the installer with the option of feeding them either from top or bottom side. All products comply to relevant Australian standards for complete peace of mind.
