Clipsal Wiser Lithium Battery Smoke Alarm Surface mount

Clipsal Wiser Lithium Battery Smoke Alarm Surface mount

Item Number: CLP599WSAL

The Wiser Lithium battery powered smoke alarm provides added peace of mind, combining a robust smoke alarm with smart home functions. When used with a Wiser hub the Wiser by SE app provides push notification alerts and Automations can trigger lights to come on if smoke is detected. New dual spectrum photoelectric sensing technology helps to mitigate false alarms for added confidence. Powered by a 10-year sealed-in lithium battery avoids the need to replace batteries.

Datasheet

Product Dimensions

Width icon

Width89 mm

Height icon

Height89 mm

Depth icon

Depth33.5 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Wiser

Range

Wiser

Product brand

Clipsal

Product or component type

smoke detector

Device application

early detection of smouldering fires and open fires

Colour tint

white (RAL 9003)

Physical

Type of packing

carton

Supply

battery

Communication network type

wireless Zigbee (2.4-2.4 GHz), 2.5 mW at < 50 m

Function available

  • local alarm
  • hush function
  • self-test of smoke detection

Control type

button (test/hush function)

Operating distance

  • 50 m indoor
  • 40 m indoor

Local signalling

  • visual: 1 LED (red) for warning and low battery
  • visual: 1 LED (green) for connection state
  • sound: signal (green)
  • sound: alarm

Type of installation

indoor

Device mounting

surface

Mounting support

  • ceiling
  • wall-mount

Fixing mode

by screws

Height

89 mm

Width

89 mm

Depth

33.5 mm

Ip degree of protection

IP20

Ambient air temperature for operation

0...45 °C

Ambient air temperature for storage

-20...60 °C

Relative humidity

0...95 %

Product certifications

Activfire

Standards

AS 3786

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

X

Environmental disclosure

ENVPEP2108022EN

Circularity profile

ENVEOLI2108022EN

Material

Material

thermoplastic

Others

Package 1 bare product quantity

1

Concentrator compatibility

Wiser hub generation 1

Mobile app name

Wiser by SE

Electronic sensor type

photo-electric sensor

[us] rated supply voltage

3 V DC

Battery type

lithium 3 V

Battery life

10 year(s)

Detection type

  • heat
  • smoke

Technology type

scattered light (Tyndall effect)

Type of measurement

smoke

Number of devices

40 for wireless alarm

Noise level

85 dB at 3 m, minimum

Time delay range

10 min (hush)

Main colour tint

white

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

6.0 cm

Package 1 width

11.5 cm

Package 1 length

12.5 cm

Package 1 weight

238.0 g

Unit type of package 2

PAL

Number of units in package 2

432

Package 2 height

104.5 cm

Package 2 width

114.0 cm

Package 2 length

114.0 cm

Package 2 weight

139.0 kg

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

Scip number

dba5c2c8-48ec-4c9e-8e8f-c42ccee5d878

Halogen content performance

Halogen free plastic parts product

Halogen content performance

Halogen free plastic parts product

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

5.846709530357222

Global warming ; total life cycle​

6 kg CO2 eq.

Minimum percentage of recycled plastic content

0
Show all specifications

Frequently Asked Questions

When should I be testing my Wiser Smoke Alarm?

Hide Show

When installing the Wiser Smoke Alarm testing of the alarm and interconnection should be done after the product is paired to the Hub and also after any RF pairing is completed.
The Wiser Smoke Alarm is recommended to be tested monthly after installation.



Can the Wiser smoke alarm interconnect with my existing alarms?

Hide Show
The Wiser Smoke alarm (CLP599WSAL) has 433MHz RF and Zigbee 3.0 tech included, meaning they are compatible with Clipsal Fire Tek® Wireless smoke alarms 755LPSMA4 and 755RFB2 bases to allow simple upgrade opportunities
