Clipsal Saturn 4000 Grid and Cover 1 Gang, Less Mechanism

Pure White | Clipsal Saturn 4000 Grid and Cover 1 Gang, Less Mechanism

Clipsal Saturn 4000 Grid and Cover 1 Gang, Less Mechanism

Item Number: 4061-PW

This Saturn 4000 single Architrave Switch Grid Plate and Cover features an elegant finish that can greatly enhance the modern look of any room. It is designed for durability and is very easy to clean.

Datasheet

Product Dimensions

Width icon

Width34 mm

Height icon

Height97.5 mm

Depth icon

Depth12 mm

Barcode

Qty UoM EAN Colour
-
-
-
Clipsal Saturn Horizon Silver Group shot
Saturn 4000 Espresso Black 4025-EB
Clipsal Saturn 4000 Ocean Mist, 4025-OM
Saturn 4000 Pure White 4025-PW

Specifications

Design

Range of product

Saturn Series 4000

Product brand

Clipsal

Product destination

switch

Sustainable offer status

Green Premium product

Physical

Number of gangs

1 gang

Marking

without marking

Mounting position

vertical

Width

34 mm

Height

97.5 mm

Depth

12 mm

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP120506EN

Others

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Weight

36.6 g

Package 1 Height

1.5 cm

Package 1 width

4.0 cm

Package 1 Length

10.0 cm
Show all specifications

Frequently Asked Questions

hide show

Can Z4025XA accommodate 60PBI intermediate mech ?

No, the 60PBI is a push button and is only suitable for switch plates eg. Z4061VH
The Z4025XA is designed to accommodate either 60R32,60R32COOK, 60RMD20COOK or 60R16 as replacement.
It is supplied complete with 60R16 .


60PBI Z4025XA

What are dimensions of Saturn Z4061 & 4061?

Dimensions for both Z4061 & 4061:

97.5mm (H) x 34mm (W) 12mm (D)

Z4061
Please go to the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=Z4061&itemno=Z4061-ZW&backto=/search?q&tab-document-1=0
New Zealand - https://www.pdl.co.nz/products/detail?CatNo=Z4061&itemno=Z4061-ZW&backto=/search?q=Z4061&tab-document-1=0
4061
Please go to the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=4061&itemno=4061-PW&backto=/search?q=4061&tab-document-1=0#
New Zealand - https://www.pdl.co.nz/products/detail?CatNo=4061&itemno=4061-PW&backto=/search?q&tab-document-1=0

What are the characteristics of a 4061E2PUDM?

The 4061E2PUDM has the function of a push button switch as well as a rotary dimmer all rolled into one which is a great space saver for the Saturn series.

• Integrally switched modular dimming mechanism.
• Built using Clipsal Universal Dimming Technology.
• 350W power rating.
• Suitable for a wide range of load types:
• Incandescent (tungsten filament) lamps.
• 240V Halogen/Dichroic Lamps.
• Low voltage downlights using electronic transformers.
• Low voltage downlights using iron-core transformers.
• Small motor loads.
• Compatible with selected dimmable LED loads.
• User selectable soft-start/kick-start operation.
• User adjustable minimum brightness.
• Multi-gang capacity up to six (6) dimmer mechanisms per plate.
• Wall or architrave mounting options.
• Wide range of plate styles and colour variants available.
• Suitable for new installations or retrofit applications.
• Inbuilt over-current and over-temperature protection.
• Full short circuit protection (!).
• Fitted with suppressors to minimise radio frequency interference.
• Complies with Australian and International EMC Standards.

4061E2PUDM-TR

Please go to the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=4061E2PUDM&itemno=4061E2PUDM-TR&backto=%2Fsearch%3Fq%3D4061E2PUDM
New Zealand - https://www.pdl.co.nz/products/detail?CatNo=4061E2PUDM&itemno=4061E2PUDM-TR&backto=%2Fsearch%3Fq%3D4061E2PUDM

Is the Saturn dimmer 4061E2PUDM leading or trailing edge?

4061E2PUDM is leading edge.


Please go to the website via the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=4061E2PUDM&itemno=4061E2PUDM-TR&backto=/search?q=4061E2PUDM&tab-document-1=0
New Zealand - https://www.pdl.co.nz/products/detail?CatNo=4061E2PUDM&itemno=4061E2PUDM-TR&backto=/search?q=4061E2PUDM&tab-document-1=0

Can the push button dimmers be used in the saturn Zen range?

Yes, they use the standard Saturn mechs. 4061E2PUDM will fit fine.

When purchasing a ZEN dimmer what parts are required?

To assemble a ZEN Dimmer it will consist of three parts. The mechanism, ZEN Series plate and the knob kit. Alternatively you can use a push button dimmer which does not require a knob kit.
Please see the below table for the part numbers to build a plate

PartPart NumberDescription
Knob KitZ4062EDIMIncludes 4 knob's 2 white, 2 black. 1 Fan and 1 Dimmer in each colour
Rotary Dimmer4062E450UDMUniversal 450W dimmer **
4062ELEDMTrailing Edge (LED specific)**
Push Button Dimmer4061E2PUDMUniversal Integrally switched* (No knob kit required)
ZEN Grid and CoverZ4061VH1 Gang grid plate and cover in ZEN Series
Z4062VH2 Gang grid plate and cover in ZEN Series
Z4063VH3 Gang grid plate and cover in ZEN Series
Z4064VH4 Gang grid plate and cover in ZEN Series
Z4065VH5 Gang grid plate and cover in ZEN Series
Z4066VH6 Gang grid plate and cover in ZEN Series
Push button Switch60PBLNeeded to switch rotary dimmers

*Integrally switched means that the mechanism is a dimmer and a switch in one. In other words it has a built in switch.
**This dimmer will require a seperate switch to turn the dimmer on and off, meaning it will require a minimum of a 2 gang plate. Standard switch mechanism is a 60PB

For further information please visit Trade - Clipsal by Schneider Electric


Z4062EDIM

4061E2RUDM

4062E450RUDM


4062ELEDM

4061E2PUDM



Show More
Homeowner relaxed in their kitchen with Saturn 4000 light switches

Range

Simplicity. Beauty. Style.

The Clipsal Saturn 4000 Series is specifically designed to offer a seamless electrical solution for the home. It offers stylish wall switches and sockets with the choice of glass-look fascia’s in three distinctive colours, or the metallic finishes of Saturn Horizon.

Saturn 4000 goes beyond simple light switches and power points. It is a complete electrical accessory solution that gives superior functionality while enhancing your home’s décor.

Its revolutionary push button technology gives you smooth reliable operation at the touch of a button. And the architecturally designed fascias look great and are a breeze to clean.
