Clipsal Iconic Switch Plate Skin 5 Gang, Horizontal/Vertical Mount

Vivid White | Clipsal Iconic Switch Plate Skin 5 Gang, Horizontal/Vertical Mount

Clipsal Iconic Switch Plate Skin 5 Gang, Horizontal/Vertical Mount

Item Number: 3045C-VW

Build this product i

Retail
$12.46
RRP (Inc. GST)
Colour Vivid White (VW)
  • Vivid White 1 PCE
  • Anthracite 1 PCE
  • Cool Grey 1 PCE
  • Warm Grey 1 PCE
  • Extra Vivid White 1 PCE

Product Dimensions

Width icon

Width78 mm

Height icon

Height120 mm

Depth icon

Depth9 mm

See full specifications

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-
Clipsal Iconic 3025 exploded view
3043G Rear Perspective

Specifications

Design

Range

Clipsal Iconic

Aesthetic name

Iconic

Product or component type

cover frame

Colour tint

vivid white (VW)

Product destination

switch

Surface treatment

untreated

Physical

Type of packing

polybag

Quantity per set

set of 20

Range compatibility

switch

Device mounting

flush

Number of rocker

5

Installation direction

horizontal/vertical

Fixing mode

clip-on

Height

120 mm

Width

78 mm

Depth

9 mm

Net weight

0.02 kg

Ambient air temperature for operation

0-45 °C

Relative humidity

10-95 %

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Not compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP120506EN

Material

Material

  • PC (polycarbonate): skin
  • ABS (acrylonitrile butadiene-styrene): skin
    • Others

      Unit Type of Package 1

      PCE

      Number of Units in Package 1

      1

      Package 1 Weight

      28 g

      Package 1 Height

      5 mm

      Package 1 width

      75 mm

      Package 1 Length

      120 mm
      Show all specifications

      Frequently Asked Questions

      hide show

      Is Iconic intermediate mechanism available assembled on a switch plate?

      Unfortunately, the Iconic intermediate mechanism is not available assembled on a plate. It can put together using below part numbers;
      40MIL  - Clipsal Iconic Intermediate Switch Mechanism, 250V, 10A, LED.
      +
      3041G - Clipsal Iconic - Switch-Grid, Vertical/Horizontal Mount, 1 Gang
      +
      3041C - Clipsal Iconic - Skin Switch Plate Cover, Vertical/Horizontal Mount, 1 Gang
      For further information, please visit the below links:
      https://www.clipsal.com/Trade/Products/ProductDetail?catno=40MIL
      https://www.clipsal.com/Trade/Products/ProductDetail?catno=3041G
      https://www.clipsal.com/Trade/search-results?q=3041C


      Do the switches in Iconic switched socket outlet have LED indicators, example 3025?

      There are no LED indicators on the switches in Iconic switched socket outlet. The switches on the outlet have green markings so you know when it is switched ON.

      For further information, please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=3025





      Will a LV432455 Vigi add on fit to a NS630H MCCB?

      A LV432455 Vigi add on will not fit a NS630H MCCB only a 32455 will fit otherwise will need to change MCCB to LV432895.


      What is the max current rating of an ATS22 relay?

      Issue:
      Max current rating of an ATS22 relay.

      Product Line:
      Altistart 22, ATS22

      Environment:
      All

      Cause:
      N/A

      Resolution:
      Max switching capability:
      5A - 250VAC or 30VDC on resistive load (p.f.=1)
      2A - 250VAC or 30VDC on inductive load (p.f=0.4)

      What is the part number for a 6 gang switch for the Iconic range?

      The part number for a 6 gang switch for the Iconic range is - 3046G & 3046C

      For further information , visit link below:-
      https://www.clipsal.com/Trade/search-results?q=3046G
      https://www.clipsal.com/Trade/search-results?q=3046C
      User-added image

      User-added image



      What is the part number of the fixed Front Connection snap-in nuts for the Compact NS100 to 630 circuit-breakers.?

      The part number of a set of 12 fixed front connection snap-in nuts is:

      29234 for Compact NS100.
      30554 for Compact NS160... 250.

      These parts are not available for Compact NS400 to 630.
      Show More

      Range

      The Clipsal Iconic range is founded on a specialised electrically safe grid plate.
      Once installed by an electrician, it’s safe for anyone to change the skins at any time by simply clipping off the standard skins and snapping on a new design.

      Iconic’s interchangeable standard, Styl and Essence skins provide clever options tailored to suit a homes’ decor or family’s lifestyle.
