Modicon M221 Memory card for M2xx controller

Item Number: TMASD1

1 PCE 0

This memory card is proposed as an option available for Modicon M221 and M221 Book logic controllers. It s used for backing up and transferring applications, loading firmware, data logging. It is also used for duplicating applications between controllers. It has 256 MB capacity. Achieve benchmark performance while increasing profitability with Modicon M221 through intuitive machine programming with EcoStruxure Machine Expert Basic.

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3595864181912	-

Specifications

Design

Range of product	Modicon M221 Modicon M251 Modicon M241
Product compatibility	logic controller

Physical

Range compatibility	Modicon M241 Modicon M221 Modicon M251
Net weight	0.004 kg
Ambient air temperature for operation	-10...70 °C
Ambient air temperature for storage	-25...85 °C
Relative humidity	0...95 % without condensation
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Reach regulation	Free of Substances of Very High Concern above the threshold
China rohs regulation	X
Eu rohs directive	Compliant

Others

Life cycle assessment data	No
If one of the deliverables is not relevant please give the reason	Accessory
Substance regulation data deliverable	Yes
Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	50
Average percentage of recycled plastic content	0 %
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty duration(in months) bmecat	18
	At least in Europe
Accessory / separate part type	SD card
Memory type	flash
Memory capacity	256 MB
Accessory / separate part category	separate parts
Product specific application	program transfer application backup
Mtbf reliability	3000000 H
Data retention time	10 year(s) at 25 °C
Number of read/write cycles	100000
Resistance to electrostatic discharge	15 kV in air conforming to IEC 61000-4-2 4 kV on contact conforming to IEC 61000-4-2
Vibration resistance	1 gn conforming to IEC 61131-2 2007
Shock resistance	15 gn conforming to IEC 61131-2 2007
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	1.000 cm
Package 1 width	12.000 cm
Package 1 length	14.500 cm
Package 1 weight	25.000 g
Unit type of package 2	S02
Number of units in package 2	50
Package 2 height	15.000 cm
Package 2 width	30.000 cm
Package 2 length	40.000 cm
Package 2 weight	1.566 kg
Sustainable packaging	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
China rohs label	1
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18

Show all specifications
