Compact NSX 1 3P Short Terminal Shield

short terminal shield - 2 poles-4 poles - for NSX100..250

1 3P short terminal shield- NSX100-250 circuit breaker accessory

Back to Accessories Home ... Product Catalogue Circuit Protection Power Breakers and Switches MCCBs < 630a="" -="" moulded="" case="" circuit=""> Compact NSX 100 - 630A Accessories

Compact NSX 1 3P Short Terminal Shield

Item Number: LV429515

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480019890	-

For more information

Visit se.com ➚

Specifications

Design

Range of product

ComPacT NSX100...250 new generation
ComPacT NSX100...250 DC new generation
ComPact NSX100...250
ComPact NSX100...250 DC

Range

ComPacT

Product or component type

short terminal shield

Product compatibility

circuit-breaker
plug-in base

Sustainable offer status

Green Premium product

Warranty

18 months

Physical

Range compatibility

ComPacT new generation (ComPacT NSX100 new generation)
ComPacT new generation (ComPacT NSX160 new generation)
ComPacT new generation (ComPacT NSX250 new generation)
ComPact (ComPact NSX100)
ComPact (ComPact NSX160)
ComPact (ComPact NSX250)
ComPacT new generation (ComPacT NSX DC new generation) NSX100 DC
ComPacT new generation (ComPacT NSX DC new generation) NSX160 DC
ComPacT new generation (ComPacT NSX DC new generation) NSX250 DC
ComPact Compact NSX100 DC
ComPact Compact NSX160 DC
ComPact Compact NSX250 DC
EasyPact (EasyPact CVS100)
EasyPact (EasyPact CVS160)
EasyPact (EasyPact CVS250)

Quantity per set

IP degree of protection

IP40 conforming to IEC 60529

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Pro-active compliance (Product out of EU RoHS legal scope)

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental Disclosure

ENVPEP111251EN

California proposition 65

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Package 1 Bare Product Quantity

Accessory / separate part type

insulation accessories

Poles description

Connection pitch

35 mm

Compatibility code

terminal shields

Unit Type of Package 1

PCE

Number of Units in Package 1

Package 1 Height

3.6 cm

Package 1 Width

12.6 cm

Package 1 Length

16.2 cm

Package 1 Weight

58 g

Unit Type of Package 2

S04

Number of Units in Package 2

Package 2 Height

30 cm

Package 2 Width

40 cm

Package 2 Length

60 cm

Package 2 Weight

4.174 kg

Unit Type of Package 3

P12

Number of Units in Package 3

240

Package 3 Height

45 cm

Package 3 Width

80 cm

Package 3 Length

120 cm

Package 3 Weight

31 kg
