Acti 9 Overvoltage Release Imsu, Threshold, 255V to 400V

Back to Auxiliaries & Accessories to Suit MCBs, RCCBs & RCBOs Home Acti 9 System Auxiliaries & Accessories to Suit MCBs, RCCBs & RCBOs

Acti 9 Overvoltage Release Imsu, Threshold, 255V to 400V

Acti 9 Overvoltage Release Imsu, Threshold, 255V to 400V

Item Number: A9N26500

Retail
$341.34
RRP (Inc. GST)
Where To Buy

Product Dimensions

Width icon

Width18 mm

Height icon

Height82.5 mm

Depth icon

Depth73.5 mm

See full specifications

Datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range

  • Acti 9
  • Prodis
  • Clario
  • Librio

      • Product or component type

      overvoltage release

      Range of product

    • DPN
    • ProDis
    • C120
    • Clario
    • Librio
    • DPN Vigi
    • ID

        • Product compatibility

      • IDc
      • ID C40
      • C120
      • C40
      • C60
      • iDPN
      • DPN Vigi
      • ITG40
      • DT40

          • Market segment

        • small commercial
        • residential

            • Sustainable offer status

            Green Premium product

            Warranty

            18 months

            Physical

            Range compatibility

          • Acti 9 iDPN
          • Acti 9 C120
          • Acti 9 C40
          • Acti 9 C60H-DC
          • Acti 9 C60NA-DC
          • Acti 9 C60PV-DC
          • Acti 9 DPN Vigi
          • Acti 9 DT40
          • Acti 9 ID C40
          • Acti 9 IDc
          • Acti 9 ITG40
          • Acti 9 ID
          • Acti 9 DPN

              • Local signalling

              action indicator

              Mounting mode

              fixed

              Mounting support

              35 mm symmetrical DIN rail

              Height

              82.5 mm

              Width

              18 mm

              Depth

              73.5 mm

              Net weight

              66 g

              Connections - terminals

            • screw clamp terminal (bottom) - 2 cable(s) 1.5-1.5 mm² - flexible
            • screw clamp terminal (bottom) - 2 cable(s) 1.5-1.5 mm² - flexible with ferrule
            • screw clamp terminal (bottom) - 1 cable(s) 0.5-2.5 mm² - rigid

                • Wire stripping length

              • 9 mm
              • 10 mm for bottom connection

                  • Standards

                  EN 50550

                  Relative humidity

                  95-95 % at 55-55 °C

                  Ambient air temperature for operation

                  -25-50 °C

                  Ambient air temperature for storage

                  -40-85 °C

                  REACh Regulation

                  Free of Substances of Very High Concern above the threshold

                  EU RoHS Directive

                  Compliant

                  Mercury free

                  Yes

                  RoHS exemption information

                  Yes

                  China RoHS Regulation

                  Product out of China RoHS scope. Substance declaration for your information

                  Environmental Disclosure

                  ENVPEP1304030

                  Circularity Profile

                  ENVEOLI1304030

                  Others

                  Device short name

                  MSU

                  [Uc] control circuit voltage

                  230 V AC 50/60 Hz

                  Threshold tripping voltage

                • 255 V
                • 275 V 3...15 s
                • 300 V 1...5 s
                • 350 V 0.25...0.75 s
                • 400 V 0.07...0.2 s

                    • 9 mm pitches

                    2

                    Tightening torque

                    1-1 N.m bottom

                    Compatibility code

                    MSU

                    Quality labels

                    CE

                    Tropicalisation

                    2 conforming to EN/IEC 60947-5-1

                    Unit Type of Package 1

                    PCE

                    Number of Units in Package 1

                    1

                    Package 1 Weight

                    74 g

                    Package 1 Height

                    2.8 cm

                    Package 1 width

                    8 cm

                    Package 1 Length

                    9.5 cm

                    Unit Type of Package 2

                    BB1

                    Number of Units in Package 2

                    8

                    Package 2 Weight

                    656 g

                    Package 2 Height

                    10 cm

                    Package 2 width

                    10 cm

                    Package 2 Length

                    27 cm

                    Unit Type of Package 3

                    S03

                    Number of Units in Package 3

                    72

                    Package 3 Weight

                    6.406 kg

                    Package 3 Height

                    30 cm

                    Package 3 width

                    30 cm

                    Package 3 Length

                    40 cm

                    WEEE

                    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
                    Show all specifications

                    Frequently Asked Questions

                    hide show

                    What is the code for the Acti9 Padlock?

                    The code is A9A26970

                    Padlocking device to fit Domae MCB

                    the Acti9 A9A26970 will fit on the domae breakers.

                    will the A9A26929 fit on a C60-DC MCB?

                    No, those are designed to fit onto the acti9 AC MCBs for those MCBs use the A9N26929

                    What are the part numbers for Padlocking device which will go on LHS and RHS of an Acti 9 iC60 MCB?

                    Part number A9A26380 is for mounting on the left side of Circuit Breaker.
                    Part number A9A26381 is for mounting on the  Right side of Circuit breaker.
