Flush Plate, 2 Gang, Intermediate

White Electric | Flush Plate, 2 Gang, Intermediate

Flush Plate, 2 Gang, Intermediate

Item Number: 32B-WE

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product destination

switch

Sustainable offer status

Green Premium product

Range of product

Standard Series

Product brand

Clipsal

Physical

Number of gangs

2 gangs

Fixing mode

by screws

Marking

without marking

Mounting position

horizontal and vertical

Fixing center

55 mm

Length

95 mm

Width

48 mm

Depth

10 mm

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP120506EN

Material

Material

plastic

Others

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Weight

28.5 g

Package 1 Height

1.1 cm

Package 1 width

5 cm

Package 1 Length

9.5 cm

Unit Type of Package 2

BB1

Number of Units in Package 2

20

Package 2 Weight

0.634 kg

Package 2 Height

9.5 cm

Package 2 width

10.2 cm

Package 2 Length

18.1 cm

Unit Type of Package 3

CAR

Number of Units in Package 3

200

Package 3 Weight

7.0 kg

Package 3 Height

21.4 cm

Package 3 width

29.7 cm

Package 3 Length

42.9 cm
Show all specifications

Documents & downloads

hide show
Filter items
  • All

  • Product Brochures

  • Technical Data Catalogues

Frequently Asked Questions

hide show

Need to access the webpage for the M340 ModbusPlus Proxy module but the webpages are not displaying.

Uninstall the current 64bit Java version and install a 32bit Java 8 version and launch with Internet Explorer.

What is the alternative to the LC2D32BNE Tesys Green reversing contactor?

LC1D32BNE x 2 + LAD9R1V

LC1D32BNE
Please go to the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=LC1D32BNE&itemno=LC1D32BNE&backto=/search?q=LC1D32BNE&tab-document-1=0
https://www.se.com/au/en/product/LC1D32BNE/tesys-deca-contactor-3p-32a-ac-3-up-to-440v-coil-24-60v-ac-dc/
New Zealand - https://www.se.com/nz/en/product/LC1D32BNE/tesys-deca-contactor-3p-32a-ac-3-up-to-440v-coil-24-60v-ac-dc/

LAD9R1V
Please go to the following links below and check under the Documentation Tab for more information.

Australia - https://www.clipsal.com/products/detail?CatNo=LAD9R1V&itemno=LAD9R1V&backto=/search?q=LAD9R1V&tab-document-1=0
https://www.se.com/au/en/product/LAD9R1V/kit-for-assembling-3p-reversing-contactors%2C-lc1d09-d38-with-screw-clamp-terminals%2C-with-electrical-interlock/
New Zealand - https://www.se.com/nz/en/product/LAD9R1V/kit-for-assembling-3p-reversing-contactors%2C-lc1d09-d38-with-screw-clamp-terminals%2C-with-electrical-interlock/

What is the dimension of 31BLA and 32BLA intermediate sized, vertical mount, flush switches?

The dimension of 31BLA and 32BLA intermediate sized flush switches are 95 mm Length x 48 mm Width x 11 mm Depth. Mounting centres are 78mm apart. The switches are rated to 250V AC/10A, 1 way/2 way.
For further information, please visit https://updates.clipsal.com/ClipsalOnline/Files/Brochures/A0000108.pdf




What are the ranges of the Square D Circuit Breakers?

MaterialDescriptionCommentDirect Replacement
QO106EC10MINIATURE CIRCUIT BREAKER 240V 6ADiscontinuedno replacement
QO110EC10QOvs 1P 10A 10kA Type CDirect ReplacementQO110VSC10
QO116EC10QOvs 1P 16A 10kA Type CDirect ReplacementQO116VSC10
QO120EC10QOvs 1P 20A 10kA Type CDirect ReplacementQO120VSC10
QO125EC10QOvs 1P 25A 10kA Type CDirect ReplacementQO125VSC10
QO132EC10QOvs 1P 32A 10kA Type CDirect ReplacementQO132VSC10
QO140EC10QOvs 1P 40A 10kA Type CDirect ReplacementQO140VSC10
QO150EC10QOvs 1P 50A 10kA Type CDirect ReplacementQO150VSC10
QO163EC10QOvs 1P 63A 10kA Type CDirect ReplacementQO163VSC10
QOH180XAUSMCB QOH 1P 80A 6KADiscontinuedno replacement
QOH1100XAUSMCB QOH 1P 100A 6KADiscontinuedno replacement
QO310EC10QOvs 3P 10A 10kA Type CDirect ReplacementQO310VSC10
QO316EC10QOvs 3P 16A 10kA Type CDirect ReplacementQO316VSC10
QO320EC10QOvs 3P 20A 10kA Type CDirect ReplacementQO320VSC10
QO325EC10QOvs 3P 25A 10kA Type CDirect ReplacementQO325VSC10
QO332EC10QOvs 3P 32A 10kA Type CDirect ReplacementQO332VSC10
QO340EC10QOvs 3P 40A 10kA Type CDirect ReplacementQO340VSC10
QO350EC10QOvs 3P 50A 10kA Type CDirect ReplacementQO350VSC10
QO363EC10QOvs 3P 63A 10kA Type CDirect ReplacementQO363VSC10
QOH380XAUSMCB QOH 3P 80A 6KADiscontinuedno replacement

RCBO
QOE110BO3QOE RCBO 1P+N 10A B 30mA 10kADirect ReplacementQO110B10RCBO30F
QOE116BO3QOE RCBO 1P+N 16A B 30mA 10kADirect ReplacementQO116B10RCBO30F
QOE120BO3QOE RCBO 1P+N 20A B 30mA 10kADirect ReplacementQO120B10RCBO30F
QOE132BO3QOE RCBO 1P+N 32A B 30mA 10kADirect ReplacementQO132B10RCBO30F
QOE140BO3QOE RCBO 1P+N 40A B 30mA 10kADirect ReplacementQO140B10RCBO30F

What are the mounting centres for part number 32BA?

The part number 32BA has 55mm mounting centres.


Please go to the link for more information:
https://www.clipsal.com/products/detail?CatNo=32BA&itemno=32BA-WE&backto=/search?q=32BA&tab-document-1=0

What are the replacement part numbers for a Square D RCBOs example QOE120B03?

Please see attached document for the charcateristics of the new RCBos and below table shows the replacemnet part#s
RCBO
MaterialAlternative MaterialDescriptionComment
QOE110BO3QO110B10RCBO30FQOE RCBO 1P+N 10A B 30mA 10kADirect Replacement
QOE116BO3QO116B10RCBO30FQOE RCBO 1P+N 16A B 30mA 10kADirect Replacement
QOE120BO3QO120B10RCBO30FQOE RCBO 1P+N 20A B 30mA 10kADirect Replacement
QOE132BO3QO132B10RCBO30FQOE RCBO 1P+N 32A B 30mA 10kADirect Replacement
QOE140BO3QO140B10RCBO30FQOE RCBO 1P+N 40A B 30mA 10kADirect Replacement
