Clipsal Iconic Gridplate and Skin 1 Gang, Vertical/Horizontal

Vivid White | Clipsal Iconic Gridplate and Skin 1 Gang, Vertical/Horizontal

Clipsal Iconic Gridplate and Skin 1 Gang, Vertical/Horizontal

Item Number: 3041VH-VW

Build this product i

Retail
$12.72
RRP (Inc. GST)
Colour Vivid White (VW)
  • Vivid White 1 PCE
  • Extra Vivid White 1 PCE

Product Dimensions

Width icon

Width78 mm

Height icon

Height120 mm

Embedding depth icon

Embedding depth15 mm

See full specifications

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-
Clipsal Iconic 3025 exploded view
3043G Rear Perspective

Specifications

Design

Range

Clipsal Iconic

Aesthetic name

Iconic

Product or component type

cover frame

Colour tint

vivid white (VW)

Product destination

switch

Surface treatment

untreated

Physical

Type of packing

polybag

Quantity per set

set of 20

Range compatibility

switch

Number of rocker

1

Installation direction

horizontal/vertical

Fixing mode

screw

Height

120 mm

Width

78 mm

Depth

7.5 mm

Embedding depth

15 mm

Net weight

0.04 kg

Ambient air temperature for storage

0-60 °C

Ambient air temperature for operation

0-45 °C

Relative humidity

10-95 %

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Not compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP120506EN

Material

Device composition

fixing frame

Material

  • PC (polycarbonate): grid plate
  • PP (polypropylene): flaps
  • POM (polyoxymethylene): locking bar
  • PC (polycarbonate): skin
  • ABS (acrylonitrile butadiene-styrene): skin
    • Others

      Package 1 Weight

      39.53 g

      Package 1 Height

      35.33 mm

      Package 1 width

      71.06 mm

      Package 1 Length

      115.05 mm
      Show all specifications

      Frequently Asked Questions

      hide show

      Will a 30USBC mech fit a 4061VH or similar plates?

      No, a 30USBC mech will not fit a 4061VH or 4061PBL or similar plates
      30USBC mechs will only fit a 4031VH or similar communication plates as 30USBC is a 30 series style of mech

      Do you do a 2031VH in red?

      Yes the part number is 2031VH-RD

      What is the part number for the 1 gang Iconic switch , and can the mech be rotated for horizontal or vertical switch plates?

      The part number for the 1 gang Iconic switch , and can the mech be rotated for horizontal or vertical switch plates - 3041VA and yes can be mounted Vertical or Horizontal..
      For further information , visit link below:-
      https://www.clipsal.com/Trade/search-results?q=3041VA
      User-added image

      Can you get a clipsal plate 2031VH with a 30HM-WE pre assembled?

      No, unfortunately you will need to buy the parts separately.

      Can we buy cover only of a saturn 4031VH product?

      No, you will have to buy the whole product 4031VH plate and grid assembly.

      Will part number 30PB fit into 4031VH plate?

      Part number 30PB will fit standard into 4031VH plate.
      Show More

      Range

      The Clipsal Iconic range is founded on a specialised electrically safe grid plate.
      Once installed by an electrician, it’s safe for anyone to change the skins at any time by simply clipping off the standard skins and snapping on a new design.

      Iconic’s interchangeable standard, Styl and Essence skins provide clever options tailored to suit a homes’ decor or family’s lifestyle.
