Clipsal - Max 4 RCBO SLIM 1PN 32A C curve 10 mAType A 6000A

Home ProductsCircuit ProtectionMax 4RCBO SLIM

Clipsal - Max 4 RCBO SLIM 1PN 32A C curve 10 mAType A 6000A

Item Number:

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

MAX4

Product or component type

residual current breaker with overcurrent protection (RCBO)

Product brand

Clipsal

Device application

distribution

Physical

[in] rated current

32 A

[ue] rated operational voltage

240 V AC

Local signalling

ON/OFF indication

Mounting mode

clip-on

Mounting support

DIN rail

Ip degree of protection

  • IP20 conforming to IEC 60529
  • IP40 (modular enclosure) conforming to IEC 60529

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Compliant

Eu rohs directive

Compliant

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Outside of Europe

Warranty duration(in months) bmecat

18

Weee label

N/A

Poles description

1P + N

Neutral position

left

Number of modules

1

Number of protected poles

1

Network type

AC

Trip unit technology

thermal-magnetic

Curve code

C

Earth-leakage sensitivity

10 mA

Earth-leakage protection class

type A

Breaking capacity

6000 A

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

0.02 cm

Package 1 width

0.076 cm

Package 1 length

0.098 cm

Package 1 weight

0.141 kg

Sustainable packaging

No

Warranty (in months)

18
Show all specifications
