Clipsal - Max 4 Combination Residual Current Device 4 Module, 4 Phase,300mA, S Type

Home ProductsCircuit ProtectionMax 4Combination Residual Current Device

Clipsal - Max 4 Combination Residual Current Device 4 Module, 4 Phase,300mA, S Type

Item Number: 4RC463S300

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

MAX4

Product or component type

residual current circuit breaker (RCCB)

Product brand

Clipsal

Physical

[in] rated current

63 A

[ue] rated operational voltage

415 V AC

Mounting support

DIN rail

Standards

AS/NZS 61008

Ip degree of protection

IP40

Ambient air temperature for operation

-5...40 °C

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Compliant

Eu rohs directive

Compliant

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Weee label

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Warranty duration(in months) bmecat

18

At least in Europe

Poles description

4P

Number of modules

4

Earth-leakage sensitivity

300 mA

Earth-leakage protection class

type AC

[uimp] rated impulse withstand voltage

6 kV

Size

81 x 72 x 75 mm conforming to DIN 43880

Pollution degree

2

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

8.5 cm

Package 1 width

9.3 cm

Package 1 length

7.7 cm

Package 1 weight

366 g

Sustainable packaging

No

Weee label

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Warranty (in months)

18
Show all specifications
