Acti9 Residual current breaker with overcurrent protection (RCBO) iC60H2 RCBO, 2P, 16A, 30mA, A type, 10000A

Item Number: A9D11216

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width36 mm

Height110 mm

Depth75.5 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480558733	-

Specifications

Design

Range	Acti9
Product or component type	residual current breaker with overcurrent protection (RCBO)

Physical

[in] rated current	16 A at 50 °C
[ue] rated operational voltage	230/240 V AC 50/60 Hz
Control type	toggle
Local signalling	ON/OFF indication
Mounting mode	clip-on
Mounting support	DIN rail
Height	110 mm
Width	36 mm
Depth	75.5 mm
Net weight	332 g
Mechanical durability	20000 cycles
Electrical durability	5000 cycles
Connections - terminals	screw clamp terminal (top) 1-25 mm² rigid without cable end screw clamp terminal (top) 1-16 mm² flexible screw clamp terminal (bottom) 1-16 mm² rigid without cable end screw clamp terminal (bottom) 1-10 mm² flexible
Wire stripping length	power circuit: 13 mm for bottom connection power circuit: 14 mm for top connection
Standards	IEC 61009-1 IEC 61009-2-2 AS/NZS 61009.1
Ip degree of protection	IP20
Relative humidity	95 % at 55 °C
Ambient air temperature for operation	-15...60 °C
Ambient air temperature for storage	-40...85 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1210008EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	27
Package 3 bare product quantity	864
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circuit breaker application	distribution
Product name	Acti9 iC60 RCBO
Device short name	iC60H2 RCBO
Poles description	2P
Earthing system	TN TT IT
Curve code	C
Earth-leakage sensitivity	30 mA
Breaking capacity	10000 A Icn at 230/240 V AC 50/60 Hz
Neutral position	left
Number of protected poles	2
Device location in system	outgoer
Network frequency	50 Hz
Network type	AC
Trip unit technology	thermal-magnetic
Breaking capacity code	H2
Residual current tripping technology	voltage dependent
Earth-leakage protection time delay	instantaneous
Earth-leakage protection class	type A
[icw] rated short-time withstand current	Icw: 250 A during 8/20 µs impulse withstand
[ics] rated service breaking capacity	7500 A at 230/240 V AC 50/60 Hz
Limitation class	3
[ui] rated insulation voltage	400 V AC 50/60 Hz
[uimp] rated impulse withstand voltage	4 kV
Surge current	250 A
Suitability for isolation	yes
Contact position indicator	yes
Comb busbar and distribution block compatibility	NO
9 mm pitches	4
Provision for padlocking	padlockable with padlock Ø 4 mm
Locking options description	ON/OFF locking facilities
Tightening torque	power circuit: 3.5...3.5 N.m top power circuit: 2 N.m bottom
Earth-leakage protection	integrated
Tropicalisation	2
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	13.6 cm
Package 1 width	4.4 cm
Package 1 length	9.2 cm
Package 1 weight	306.0 g
Unit type of package 2	S02
Number of units in package 2	27
Package 2 height	15 cm
Package 2 width	30 cm
Package 2 length	40 cm
Package 2 weight	8.668 kg
Unit type of package 3	P12
Number of units in package 3	864
Package 3 height	70.0 cm
Package 3 width	120.0 cm
Package 3 length	80.0 cm
Package 3 weight	276.384 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0
Carbon footprint of the manufacturing phase [a1 to a3]	0 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	Yes
Carbon footprint of the end-of-life phase [c1 to c4]	0
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Halogen-free status	Halogen free plastic parts product
Silicone-free	No
F-gas free	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	0
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	Yes
Scip number	170f0083-3431-44d4-b5b4-c8b8e68e05e4
Halogen-free status	Halogen free plastic parts product
Silicone-free	No
End of life manual availability	N/A
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18
