Acti9 Single push-button 1NO grey, indicator light Green 110-230Vac

Home ProductsCircuit ProtectionActi 9Single push-button

Acti9 Single push-button 1NO grey, indicator light Green 110-230Vac

Item Number: A9E18036

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width18 mm

Height icon

Height82 mm

Depth icon

Depth71.5 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

iPB

Range

Acti9

Product or component type

push-button

Market segment

  • residential
  • small commercial

Warranty

18 months

Physical

Standards

  • IEC 60669-1
  • IEC 60947-5-1

[ie] rated operational current

20 A

[ue] rated operational voltage

250 V AC

Control type

1 push-button grey

Local signalling

LED indicator green, service life 100000 h of constant lighting efficiency (consumption 0.3 W)

Mounting mode

fixed

Mounting support

35 mm symmetrical DIN rail

Height

82 mm

Width

18 mm

Depth

71.5 mm

Electrical durability

AC-22: 30000 cycles AC 50/60 Hz

Connections - terminals

  • staggered tunnel terminal1 cable(s) 0.5-0.5 mm² rigid
  • staggered tunnel terminal1 cable(s) 0.5-0.5 mm² flexible
  • staggered tunnel terminal1 cable(s) 0.5-0.5 mm² flexible with ferrule
  • staggered tunnel terminal2 cable(s) 2.5-2.5 mm² rigid
  • staggered tunnel terminal2 cable(s) 2.5-2.5 mm² flexible
  • staggered tunnel terminal2 cable(s) 2.5-2.5 mm² flexible with ferrule

Wire stripping length

9 mm

Relative humidity

95 % at 55 °C

Ambient air temperature for operation

-35...70 °C

Ambient air temperature for storage

-40...80 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP110301EN

Circularity profile

N/A

California proposition 65

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Package 1 bare product quantity

1

Product name

Acti9 iPB

Device short name

iPB

Contacts type and composition

1 NO

Signalling circuit voltage

AC: 110...230 V 50/60 Hz

Comb busbar and distribution block compatibility

  • upside: Clario
  • upside: Librio
  • upside: ProDis

9 mm pitches

2

Tightening torque

1 N.m

Compatibility code

iPB

Tropicalisation

2

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

8.5 cm

Package 1 width

2 cm

Package 1 length

8 cm

Package 1 weight

46 g

Unit type of package 2

BB1

Number of units in package 2

12

Package 2 height

8 cm

Package 2 width

10 cm

Package 2 length

23 cm

Package 2 weight

607 g

Unit type of package 3

S03

Number of units in package 3

108

Package 3 height

30 cm

Package 3 width

30 cm

Package 3 length

40 cm

Package 3 weight

5.95 kg

Packaging made with recycled cardboard

No

Packaging without single use plastic

Yes

Bvb url

https://byggvarubedomningen.se/

Green premium status for reporting

Green Premium product

Scip number

1f68db37-1d35-43e3-91db-a07321e19eb2

Bvb

Accepted

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Optimized energy efficiency

False

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Minimum percentage of recycled plastic content

0
