Acti9, Centralized control and remote indication, iATLc+s

Item Number: A9C15409

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width18 mm

Height icon

Height86 mm

Depth icon

Depth71 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Acti9

Range

Acti9

Product or component type

centralized control and remote indication auxiliary

Product compatibility

  • iTL (32 A)
  • iTL (16 A)

Market segment

  • residential
  • small commercial

Warranty

18 months

Physical

Mounting mode

fixed, on right side of TL

Mounting support

DIN rail

Height

86 mm

Width

18 mm

Depth

71 mm

Connections - terminals

  • tunnel type terminals0.5-4 mm² - rigid
  • tunnel type terminals0.5-4 mm² - rigid - with cable end
  • tunnel type terminals1-4 mm² - flexible
  • tunnel type terminals1-4 mm² - flexible - with cable end

Wire stripping length

11 mm

Range compatibility

  • Acti 9 Acti9 iTL iTL
  • Acti 9 Acti9 iTL iTLi
  • Acti 9 Acti9 iTL iTLs

Ip degree of protection

IP20 conforming to IEC 60529

Relative humidity

95 % at 55 °C

Ambient air temperature for operation

-20...50 °C

Ambient air temperature for storage

-40...70 °C

Standards

EN/IEC 60669-2-2

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

China rohs regulation

X

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2311015EN

Circularity profile

N/A

Others

Package 1 bare product quantity

1

Packaging made with recycled cardboard

No

Packaging without single use plastic

Yes

Device short name

iATLc+s

Signal contacts composition

1 C/O

Signalling circuit voltage

  • 24 V AC/DC: 10 mA
  • 12...240 V AC: 50/60 Hz 6 A
  • 12...24 V DC: 6 A
  • 15...240 V AC: 50/60 Hz 2 A
  • 13...24 V DC: 2 A

[uc] control circuit voltage

24...240 V AC 50/60 Hz

[ui] rated insulation voltage

440 V

[uimp] rated impulse withstand voltage

4 kV

Total power losses

0.15 W

Power losses per pole

0.15 W

9 mm pitches

2

Tightening torque

1 N.m

Compatibility code

iATLc+s

Overvoltage category

III

Tropicalisation

2

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

2.9 cm

Package 1 width

8 cm

Package 1 length

9 cm

Package 1 weight

74 g

Unit type of package 2

BB1

Number of units in package 2

8

Package 2 height

8.5 cm

Package 2 width

9.2 cm

Package 2 length

26.5 cm

Package 2 weight

651 g

Unit type of package 3

S03

Number of units in package 3

72

Package 3 height

30 cm

Package 3 width

30 cm

Package 3 length

40 cm

Package 3 weight

6.347 kg

Bvb

Accepted

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

2.145826441

Global warming ; total life cycle​

2 kg CO2 eq.
