Clipsal Iconic Night Walk Sensor Light Motion Activated

Vivid White | Clipsal Iconic Night Walk Sensor Light Motion Activated

Clipsal Iconic Night Walk Sensor Light Motion Activated

Item Number: 3025NW-VW

The Clipsal Iconic Night Walk Sensor Light Smart Skin is a motion-activated skin for outlet sockets with a built-in motion sensor and dual-mode light. A motion-triggered LED light casts just enough light to find your way without turning on a light.

Datasheet

Product Dimensions

Width icon

Width120 mm

Height icon

Height78 mm

Depth icon

Depth32 mm

Barcode

Qty UoM EAN Colour
-
-
-
The back of the Clipsal Iconic Night Walk
Clipsal Iconic Night Walk in Room
Nightwalk side view
Clipsal Iconic Night Walk at night

Specifications

Design

Range of product

Iconic

Range

Clipsal Iconic

Aesthetic name

Iconic

Product or component type

cover frame

Colour tint

vivid white (VW)

Product destination

switched socket

Surface treatment

untreated

Sustainable offer status

Green Premium product

Physical

Type of packing

polybag

Quantity per set

set of 1

Range compatibility

Clipsal Iconic switched socket

Device mounting

flush

Number of rocker

1

Number of power socket outlets

1

[In] rated current

10 A

Movement detection area

2 m

Presence detection area

1 m

Operating distance

2 m

Installation direction

horizontal

Fixing mode

plug-in

Height

78 mm

Width

120 mm

Depth

32 mm

Ambient air temperature for storage

-5...65 °C

Ambient air temperature for operation

0...45 °C

Relative humidity

10...85 %

Product certifications

RCM

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental Disclosure

ENVPEP2106012

Circularity Profile

ENVEOLI2106012

Material

Device composition

  • 1 motion sensor 27 mA
  • 1 LED light 8 mA

Others

Package 1 Bare Product Quantity

1

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

3.2 cm

Package 1 Width

7.8 cm

Package 1 Length

12.0 cm

Package 1 Weight

0.064 kg
Show all specifications
