Canalis KDP End feed unit Canalis KDP20, 20A, right or leftmounting, without line protection, 3L+N+PE

Item Number: KDP20ABG4

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width159 mm

Height49 mm

Depth64 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480002649	-

Specifications

Design

Range	Canalis
Range of product	Canalis
Product compatibility	Canalis KDP busbar trunking 20-20 A
Product or component type	feed unit
Warranty	18 months

Physical

[ie] rated operational current	20 A
[ue] rated operational voltage	230...400 V
Protection type	without protection
Control type	without
Provided equipment	end cover
Mounting mode	by clips
Mounting support	busbar
Connections - terminals	terminal block - Pg 16 - screw clamp connector for 4-4 mm²
Width	159 mm
Depth	64 mm
Height	49 mm
Net weight	120 g
Standards	IEC 61439-6
Ip degree of protection	IP55 conforming to IEC 60529
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP061103EN
Eu rohs directive	Compliant

Material

Material	copper

Others

Life cycle assessment data	No
If one of the deliverables is not relevant please give the reason	PEP created standard configuration, but individal CR is component
Substance regulation data deliverable	Yes
Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of bio-based plastic content	0 %
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Device short name	KDP
Number of circuits	1
Busbar trunking polarity	3L + N + PE
Mounting location	left right
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	20.0 cm
Package 1 width	13.0 cm
Package 1 length	6.0 cm
Package 1 weight	192.0 g
Unit type of package 2	BB1
Number of units in package 2	25
Package 2 height	20.0 cm
Package 2 width	30.0 cm
Package 2 length	40.0 cm
Package 2 weight	6.8 kg
Unit type of package 3	P06
Number of units in package 3	300
Package 3 height	77.0 cm
Package 3 width	80.0 cm
Package 3 length	60.0 cm
Package 3 weight	90.1 kg
Sustainable packaging	No
Pvc free	Yes
Silicone-free	Yes
Energy efficiency optimized	False
F-gas free	N/A
Take-back	No
Removable battery	N/A
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	Yes
Silicone-free	Yes
End of life manual availability	N/A
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18
