C-Bus Control and Management System Plastic Plate Wall Switch 1 Button

Home ProductsSmart Home SolutionsC-BusPlastic Plate Wall Switch

C-Bus Control and Management System Plastic Plate Wall Switch 1 Button | White Electric

Item Number: 5031NL-WE

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-
c-bus house

Features

  • C-Bus® home and building automation system is commercialised under Clipsal by Schneider Electric.
  • Powerful, fully integrated system that can control and automate lighting and many other electrical systems and products
  • Implemented for commercial or residential buildings automation, it brings control, comfort, efficiency and ease of use to its occupants.

Specifications

Design

Range of product

Series 2000|C-Bus|Australian Series

Product brand

Clipsal

Physical

Device presentation

basic element with full cover plate

Control type

button

[ue] rated operational voltage

15...36 V DC

[in] rated current

18 mA

Mounting support

wall

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Under investigation

Environmental disclosure

ENVPEP2403010EN

Circularity profile

ENVEOLI2403010EN

Material

Material

plastic

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

4.8 cm

Package 1 width

9.2 cm

Package 1 length

13.5 cm

Package 1 weight

125 g

Unit type of package 2

CAR

Number of units in package 2

50

Package 2 height

25.4 cm

Package 2 width

34.8 cm

Package 2 length

44.5 cm

Package 2 weight

7.1 kg

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A
Show all specifications

Documents & downloads

hide show
Filter items
  • All

  • Product Brochures

  • CAD Files and Packs

  • Technical Data Catalogues

  • Other technical guide

  • End of Life Manual

  • Environmental Disclosure

  • Operating Manuals

  • Specification Guide

  • Application Notes

  • Software - Release

  • Software - Data Library

Frequently Asked Questions

hide show

What is the best alternative for 5012S164/4LWE?

If you are after a replacement electronic switch for a 5012S164/4L-WE then order the standard item “B5034MNLPCB-WE” which contains a PCB Assy plus the Rear Cover.

If you are after an equivalent to a 5012S164/4L-WE the closest we have can be achieved by ordering 1 x “B12/30/6-WE” + 3 x “5031NMML” + 9 x “5031NMS”






If just for replacement then you could get B503xNL and remove the Metal Plate and just use the gang switch to replace the old unit.


B5031NL, B5032NL, B5034NL



Office

Range

The contemporary styling and flexibility of the 2000 Series and C2000 range have made it Clipsal’s most popular range of switches and power points.

2000 Series and C2000 range offers a range of stylish switches in standard and architrave sizes. Power points are available in single, double and automatic models, in vertical or horizontal format, with options such as neons, extra switches and safety shutters.

The extensive product range also includes dimmers, fan speed controllers, timers, weatherproof switches and TV, data and phone sockets.
