C-Bus Control and Management System Glass Fascia 5 Gang, Saturn Series | Horizon Black

Item Number: 5085DF-HB

Pure White 1 PCE 0
Cream 1 PCE 0
Horizon Black 1 PCE 0
Stainless Steel 1 PCE 0
Black 1 PCE 0
White Glass Facia 1 PCE 0

Datasheet

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554733018	PW
1	PCE	9311554612641	30
1	PCE	9311554612658	60
10	CAR	19311554612655	60
1	PCE	9311554626730	GF
1	PCE	9311554744755	HB
40	CAR	19311554744752	HB
1	PCE	9311554685065	J0
30	CAR	19311554685062	J0

Specifications

Design

Range of product	C-Bus Australian Series Saturn Series
Range	C-Bus
Product brand	Clipsal
Product destination	switch

Physical

Control type	button
Marking	without marking
Mounting position	vertical
Fixing center	84 mm
Length	116 mm
Width	76 mm
Depth	13 mm
Number of gangs	5 gangs
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2403010EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	glass

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	1.3 cm
Package 1 width	7.6 cm
Package 1 length	11.6 cm
Package 1 weight	110.0 g
Total lifecycle carbon footprint	2 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	1.463168215992214
Carbon footprint of the manufacturing phase [a1 to a3]	1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0143485040180992
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.0883431739402775
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Halogen free product
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	1.56585989395059
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Halogen-free status	Halogen free product
Pvc free	Yes
End of life manual availability	ENVEOLI2403010EN
Take-back	No
Warranty (in months)	18
