Standard Series Single Switch Socket Outlet 250V, 10A, Standard Size, 2 Removable Extra Switch | Cream

Item Number: 15XX-CM

White Electric 1 PCE 0
Cream 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554036065	WE
5	CRT	9311554200145	WE
100	CAR	19311554102279	WE
1	PCE	9311554035990	CM
5	CRT	9311554214432	CM
50	CAR	19311554102248	CM

Specifications

Design

Range of product	Standard Series
Product or component type	switched socket
Product brand	Clipsal
Surface finish	glossy

Physical

Control type	ON/OFF button
Number of gangs	1 gang
Pin number	3
Number of power socket outlets	1
Actuator	rocker switch
Fixing mode	by screws
Local signalling	without light indicator
Mounting position	horizontal
[ue] rated operational voltage	250 V AC
[in] rated current	10 A
Depth	14 mm
Length	115 mm
Width	73 mm
Fixing center	84 mm
Standards	AS/NZS 3100 AS/NZS 3112 AS/NZS 3133 AS/NZS 3000:approval number S/1
Environmental disclosure	ENVPEP120506EN
Eu rohs directive	Compliant By Exemption

Material

Material	PC (polycarbonate)

Others

Legacy weee scope	In
Package 1 bare product quantity	1
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.5 cm
Package 1 width	11.8 cm
Package 1 length	7.1 cm
Package 1 weight	104 g
Unit type of package 2	BB1
Number of units in package 2	5
Package 2 height	12.4 cm
Package 2 width	10.8 cm
Package 2 length	14.6 cm
Package 2 weight	582 g
Unit type of package 3	CAR
Number of units in package 3	100
Package 3 height	25.4 cm
Package 3 width	34.8 cm
Package 3 length	44.5 cm
Package 3 weight	12 kg
Sustainable packaging	No
End of life manual availability	N/A
Warranty (in months)	18
