Standard Series, Single Socket Outlet, 32V, 10A, 2 PIN, Flush Mount WE
Item Number: 405/32-WE
Datasheet
Close
Specifications
Design
Product or component type
socket-outlet
Product brand
Clipsal
Physical
Quantity per set
set of 1
Marking
extra low voltage
Local signalling
without light indicator
Device mounting
flush
Fixing mode
by screws
[in] rated current
15 A
[ue] rated operational voltage
32 V DC
Depth
23 mm
Length
94 mm
Width
42 mm
Fixing center
84 mm
Standards
AS/NZS 3112|AS 3100|AS 3109|AS/NZS 3122:approval number S/1
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Others
Package 1 bare product quantity
1
Cover type
complete housing
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.3 cm
Package 1 width
4.2 cm
Package 1 length
9.4 cm
Package 1 weight
0.048 kg
