Specifications
Design
Range of product
Standard Series
Product brand
Clipsal
Colour
body: grey
Physical
[in] rated current
20 A
[ue] rated operational voltage
230 V 50/60 Hz conforming to EN 60309-2
Connections - terminals
screw terminal
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP1605009
Eu rohs directive
Compliant with Exemptions
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
plastic
Others
Legacy weee scope
In
Package 1 bare product quantity
1
Outside of Europe
Weee label
N/A
Voltage colour
blue
Plug, socket, control station shape
straight
Duration
6 h
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.5 cm
Package 1 width
4.2 cm
Package 1 length
7.1 cm
Package 1 weight
6 g
Sustainable packaging
No
Scip number
c6f2fabe-d5ba-4588-bd03-c90f7def1381
End of life manual availability
N/A
Warranty (in months)
18
