Specifications
Design
| Range of product | Standard Series |
|---|---|
| Product brand | Clipsal |
| Product destination | switch |
Physical
| Fixing mode | by screws |
|---|---|
| Marking | without marking |
| Mounting position | horizontal and vertical |
| Fixing center | 84 mm |
| Length | 115 mm |
| Width | 73 mm |
| Depth | 11 mm |
| Number of gangs | 5 gangs |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120506EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | plastic |
|---|
