Standard Series Caravan Socket Outlet Auto-Switched IP34 15A | White Electric
Item Number: 415VF15-WE
Datasheet
Close
Specifications
Design
| Product or component type | socket-outlet |
|---|---|
| Product brand | Clipsal |
Physical
| Quantity per set | set of 1 |
|---|---|
| Marking | without marking |
| Local signalling | without light indicator |
| Device mounting | flush |
| Fixing mode | by screws |
| [in] rated current | 15 A |
| [ue] rated operational voltage | 250 V AC |
| Depth | 38 mm |
| Length | 101 mm |
| Fixing center | 76 x 65 mm |
| Width | 80 mm |
| Standards |
|
| Ip degree of protection | IP34 |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2508038EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
