Standard Series Automatic Single Socket Outlet 250VAC, 10A, Panel Mount, Security Flap | White Electric
Item Number: 10PL-WE
Datasheet
Close
Specifications
Design
| Range of product | Standard Series |
|---|---|
| Product or component type | socket-outlet |
| Product brand | Clipsal |
Physical
| Quantity per set | set of 1 |
|---|---|
| Marking | without marking |
| Local signalling | without light indicator |
| Device mounting | flush |
| Fixing mode | by screws |
| [in] rated current | 10 A |
| [ue] rated operational voltage | 250 V AC |
| Depth | 22 mm |
| Length | 115 mm |
| Fixing center | 84 mm |
| Number of poles | 1 |
| Width | 73 mm |
| Standards |
|
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120506EN_V2 |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
