Pro Series Twin Power Point Grid Horizontal Mount,1Ex20A, 10A, 250V
Item Number: P3025XAG
Close
Including an extra switch, the Pro Series Horizontal Twin Switched Power Point Grid is ideal for applications where you need additional switching for lighting, exhaust fan control, a heater or cooker switch. The twin outlets are rated 10A, 250V, while the extra switch is rated 20A.
Specifications
Design
| Range | Pro Series |
|---|---|
| Product or component type | switched socket |
| Surface finish | matt |
| Surface treatment | untreated |
Physical
| Device presentation | mechanism with fixing frame |
|---|---|
| Socket number | 2 |
| Connections - terminals | screw terminals |
| Installation direction | horizontal |
| Device mounting | flush |
| Number of rocker | 3 |
| Rated current | 10 A |
| [ue] rated operational voltage | 230/240 V |
| Fixing mode | by screws |
| Clamping connection capacity |
|
| Wire stripping length | 16 mm |
| Net weight | 78 g |
| Ambient air temperature for operation | 0...45 °C |
| Height | 72 mm |
| Width | 112 mm |
| Depth | 36 mm |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2309004EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
| Quantity per set | set of 10 |
