Prestige Series Single Switch Socket Outlet 250V, 10A, Vertical, Large Format Size | White Electric

Item Number: P2015XX-WE

White Electric 1 PCE 0
Cream 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554257514	WE
5	CRT	9311554244613	WE
50	CAR	19311554274464	WE
1	PCE	9311554274405	CM
5	CRT	9311554274412	CM
50	CAR	19311554274419	CM

Specifications

Design

Range of product	Prestige Series P2000
Product or component type	switched socket
Product brand	Clipsal

Physical

Control type	ON/OFF button
Number of gangs	1 gang
Pin number	3
Number of power socket outlets	1
Actuator	rocker switch
Fixing mode	by screws
Local signalling	without light indicator
Mounting position	horizontal
[ue] rated operational voltage	250 V AC
[in] rated current	10 A
Depth	42 mm
Length	116 mm
Width	116 mm
Fixing center	84 mm
Standards	AS/NZS 3100 AS/NZS 3112 AS/NZS 3133:approval number S/1
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP120506EN_V2
Eu rohs directive	Compliant By Exemption

Material

Material	plastic

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Weee label	N/A
Weee applicability	Finished product
Warranty duration(in months) bmecat	18
Main colour tint	white electric
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	4 cm
Package 1 width	11.5 cm
Package 1 length	11.5 cm
Package 1 weight	194 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	2 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	2.2158295039157956
Carbon footprint of the manufacturing phase [a1 to a3]	2 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.025030305484745764
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.002660028718033898
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.046817445503525415
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.14239498694515257
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Pvc free	No
Silicone-free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	2.432732270567254
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	No
Silicone-free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
