Clipsal Iconic Outdoor Conduit cover 25mm diameter

Home ProductsPower Points and SwitchesIconic OutdoorConduit cover

Clipsal Iconic Outdoor Conduit cover 25mm diameter | Black

Item Number: O3000CE-25-BK

Build your Iconic

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width38 mm

Height icon

Height33.5 mm

Depth icon

Depth11.1 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-
iconic outdoor zoom in
iconic outdoor backing
iconic outdoor socket exploded view
iconic outdoor zoom in
iconic outdoor backing
iconic outdoor socket exploded view

Iconic Outdoor Features

Water and dust resistant

The Iconic Outdoor range features an innovative design to ensure your outdoor switches and sockets are kept safe and secure.

Integrated shutters seal the socket apertures, preventing water ingress and ensuring an IP54 protection rating. The switches are rated IP56.

Integrated seals fix onto conduits or cables at entry points, removing the need for additional sealants, and pre-drilled mounting holes are positioned outside of the waterproof area to prevent leaks.

Iconic Outdoor Features

Faster installation

Making it faster and easier for electrical contractors to install, the Iconic Outdoor range features large, in-line terminals on the grid. The grid also features large clips, allowing it to be attached to the frame in seconds.

A full, over-moulded rubber frame prevents slipping on the wall where it is to be installed, while also absorbing inconsistencies in the wall surface.

Iconic Outdoor Features

Aesthetically pleasing

Achieving a balance between simplicity of installation and appealing good looks, the Iconic Outdoor range utilises a bi-face system, with an aesthetically pleasing, robust cover for the consumer, which protects and hides the highly technical core which has been uniquely designed for the electrician.

A hidden “press-to-release” lock allows the cover to be easily removed and replaced, so consumers can easily update the look of their Iconic Outdoor switch or outlet.

Specifications

Design

Range

Weathershield

Product brand

Clipsal

Product or component type

conduit entry

Product compatibility

cable distribution

Physical

Width

38 mm

Depth

11.1 mm

Height

33.5 mm

Reach free of svhc

Yes

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2106012

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

ABS (acrylonitrile butadiene-styrene)

Others

Average percentage of recycled plastic content

0 %

Package 1 bare product quantity

1

Outside of Europe

Weee label

N/A

Weee applicability

Component

Weee exclusion rationale

Component not in scope – non independent function

Legacy weee scope

Out

Accessory / separate part category

installation accessory

External diameter

25 mm

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

2 cm

Package 1 width

9.5 cm

Package 1 length

6 cm

Package 1 weight

7 g

Total lifecycle carbon footprint

3 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

1.091399353009393

Carbon footprint of the manufacturing phase [a1 to a3]

1 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

0.020355906702400933

Carbon footprint of the distribution phase [a4]

0 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0.0008921250811512631

Carbon footprint of the installation phase [a5]

0 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

1.439092307692308

Carbon footprint of the use phase [b2, b3, b4, b6]

1 kg CO2 eq.

Sustainable packaging

Yes

Carbon footprint of the end-of-life phase [c1 to c4]

0.024854657111625274

Carbon footprint of the end-of-life phase [c1 to c4]

0 kg CO2 eq.

Pvc free

No

Halogen-free status

Halogen free product

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Total lifecycle carbon footprint

2.5765943495968737

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

Yes

Halogen-free status

Halogen free product

Pvc free

No

End of life manual availability

ENVEOLI2106012

Take-back

No

Warranty (in months)

18
Show all specifications

Frequently Asked Questions

What colours are the new Iconic Outdoor Products available in?

Hide Show
Iconic Outdoor is available in Matte White -XW and Matte Black -BK.

Iconic Outdoor switchIconic Outdoor switch

Do I need to use any caps or silicone on the mounting screws on the Iconic Outdoor?

Hide Show
All Iconic Outdoor mounting points are outside the wiring area and do not need to be drilled or any additional sealant applied.

showing mounting hole of Iconic Outdoor

What size conduit entries can be used with Iconic Outdoor?

Hide Show
Iconic Outdoor suits both 20mm and 25mm conduit.

Iconic Outdoor conduit entry


Do the conduit caps come with the Iconic Outdoor?

Hide Show
No, the conduit caps are supplied separately and come in two sizes 20mm and 25mm.

 Iconic Outdoor conduit entryIconic Outdoor conduit entry

How do you remove the cover from Iconic Outdoor once its clipped on?

Hide Show
To remove the cover from Iconic Outdoor, push down on the top middle of the cover and pull away from wall.

Cover clip
iconic outdoor sockets and switches

Iconic Outdoor Range

Redefining weather-proof products, Iconic Outdoor is the innovative new range which achieves a balance between simplicity of installation, clever technology and consumer friendly aesthetics.

Designed for the residential market, but with electrical contractors in mind, the range is suitable for Zone 2 applications.

Iconic Outdoor sockets have an IP54 protection rating, while the Iconic Outdoor switches have an IP56 protection rating.
