Clipsal Iconic Switch Mechanism 3-Position Toggle 250V, 10A

Clipsal Iconic Switch Mechanism 3-Position Toggle 250V, 10A | VW

Item Number: 49M-VW

With its M40 motor ratings, the Clipsal Iconic Switch Mechanism delivers versatile performance in any commercial or residential project. Its three-position toggle makes this wall switch a functional choice for most jobs.

Datasheet

Product Dimensions

Width icon

Width23 mm

Height icon

Height23 mm

Depth icon

Depth32 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal Iconic

Product or component type

switch

Device application

lighting

Colour tint

vivid white

Sustainable offer status

Green Premium product

Physical

Load type

LEDi lamp 100 W

Quantity per set

set of 20

Device presentation

mechanism

Control type

rocker

Switch function

3 positions

Marking

ON-OFF-ON

Rated current

10 A

[ue] rated operational voltage

250 V

Connections - terminals

screw terminal

Height

23 mm

Width

23 mm

Depth

32 mm

Net weight

0.016 kg

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP1802001EN

Circularity profile

ENVEOLI1802001EN

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.2 cm

Package 1 width

4.5 cm

Package 1 length

5.9 cm

Package 1 weight

20 g
Show all specifications

Frequently Asked Questions

hide show

What is the part number of Iconic 3 position switch, marked Auto-Off-Manual?

Part number of  Iconic 3 position switch mechanism is 49M rated to 250V, 10A. 49MLBL   Iconic, 3position switch dolly pack is also required.
49MLBL is labelled as follows:
Auto-Off-Manual
Sensor off manual
Up-Off-Down
For further information, please visit
http://www.clipsal.com/Trade/Products/ProductDetail?catno=49M
http://www.clipsal.com/Trade/Products/ProductDetail?catno=49MLBL
