Clipsal Iconic, Double Switch Power Point, Horizontal Mount, 250 V 10A, Extra Removable Switch

Clipsal Iconic, Double Switch Power Point, Horizontal Mount, 250 V 10A, Extra Removable Switch VW

Item Number: 3025XA-VW

Datasheet

Barcode

Qty UoM EAN Colour
1 PCE 9311554785390 VW
10 BB1 9311554789800 VW
50 CAR 19311554785397 VW

Specifications

Design

Range

Clipsal Iconic

Product or component type

switched socket

Colour tint

vivid white (VW)

Sustainable offer status

Green Premium product

Physical

Device presentation

complete product

Outlet poles configuration

2P + E with shutter

Outlet standard

Australian

Device mounting

flush

Number of power socket outlets

2

Number of rocker

3

Range compatibility

Clipsal Iconic

Outlet standard description

with earthing contact

[ue] rated operational voltage

230/240 V

Ground lug position

straight 180° position

Fixing mode

by screw

Installation direction

horizontal

Type of packing

polybag

Quantity per set

set of 10

Sale per indivisible quantity

1

Rated current

10 A at 230/240 V AC 50 Hz

Electrical durability

12000 cycles

Screwdriver shape

square drive no 1 (SQ1)|Philips No 2

Clamping connection capacity

1 x 2.5...4 x 2.5 mm² for stranded cable(s)|1 x 2.5...4 x 2.5 mm² for flexible cable(s)|1 x 2.5...4 x 2.5 mm² for rigid cable(s)

Wire stripping length

16 mm

Height

78 mm

Width

120 mm

Depth

37 mm

Net weight

0.092 kg

Ambient air temperature for storage

0...60 °C

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

Standards

AS/NZS 3112|AS/NZS 3133|AS/NZS 60669.1

Product certifications

RCM

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Rohs exemption information

Yes

Environmental disclosure

ENVPEP1607004EN

Material

Material

PC (polycarbonate): cover frame|ABS (acrylonitrile butadiene-styrene): cover frame|PC (polycarbonate): fixing frame|PP (polypropylene): rocker|POM (polyoxymethylene): shutter|POM (polyoxymethylene): locking bar

Others

Package 1 bare product quantity

1

Outlet standard deviation

Australian/New Zealand

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

4.4 cm

Package 1 width

8.7 cm

Package 1 length

14.4 cm

Package 1 weight

132 g
