2000 Series Quad Switch Socket Outlet 2 Gang, Grid Plate and Surround | Black

Item Number: 2025H2-BK

White Electric 1 PCE 0
Black 1 PCE 0
Cream 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554657178	WE
5	CRT	9311554657185	WE
50	CAR	19311554657175	WE
1	PCE	9311554657079	BK
5	CRT	9311554657086	BK
50	CAR	19311554657076	BK
1	PCE	9311554657116	CM
5	CRT	9311554657123	CM
50	CAR	19311554657113	CM

Specifications

Design

Range of product	Gangbusters
Product or component type	switched socket
Product brand	Clipsal
Surface finish	glossy

Physical

Control type	ON/OFF button
Number of gangs	4 gangs
Pin number	3
Number of power socket outlets	4
Actuator	rocker switch
Fixing mode	by screws
Local signalling	without light indicator
Mounting position	horizontal
[ue] rated operational voltage	250 V AC
[in] rated current	10 A
Fixing center	84 mm
Standards	AS/NZS 3100 AS/NZS 3112 AS/NZS 3133:approval number S/1
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP120506EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	plastic

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	5
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.5 cm
Package 1 width	7.5 cm
Package 1 length	23.2 cm
Package 1 weight	255.6 g
Unit type of package 2	BB1
Number of units in package 2	5
Package 2 height	3.7 cm
Package 2 width	25.2 cm
Package 2 length	44.4 cm
Package 2 weight	1.336 kg
Total lifecycle carbon footprint	2 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	1.2510834839140046
Carbon footprint of the manufacturing phase [a1 to a3]	1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.047273746360296215
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.008559310115303543
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.1056339273201361
Carbon footprint of the use phase [b2, b3, b4, b6]	0.1 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.6234317847599175
Carbon footprint of the end-of-life phase [c1 to c4]	0.6 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	2.035982252469658
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
China rohs label	5
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
