2000 Series Flush Surround and Grid Plate 2 Gang, Vertical/Horizontal Mount | Red
Item Number: 2032VH-RD
The Clipsal 2000 Series 2 Gang Surround and Grid Plate is ready to take on whatever mechanism and switch type you require. The product is suitable for either vertical or horizontal mounting and it has a gloss finish and rounded edges, making it easy to keep clean.
Datasheet
Features
- Cover hides all mounting holes and is easily removed to enable you to paint right up to the edge of the grid plate without having to worry about marking the cover.
- Hardwearing, UV stabilised surface
Specifications
Design
| Range of product | Series 2000 |
|---|---|
| Product brand | Clipsal |
| Product or component type | blank plate |
| Product destination | switch |
Physical
| Fixing mode | by screws |
|---|---|
| Marking | without marking |
| Mounting position | horizontal and vertical |
| Fixing center | 84 mm |
| Length | 116 mm |
| Width | 76 mm |
| Depth | 13 mm |
| Number of gangs | 2 gangs |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120506EN_V2 |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | plastic |
|---|
