2000 Series Automatic Single Socket Outlet 250VAC, 10A | White Electric
Item Number: 2010-WE
For situations where you have an appliance to plug in, PLUS a circuit to operate, the Clipsal 2000 Series Single Switched Socket with Removable Extra Switch is exactly what you need. Turn on your lights, exhaust fan, or heater, while plugging in your hairdryer. The outlet also has a safety shutter for extra protection.
Datasheet
Features
- Gloss surface finish
- Choice of single, double and automatically switched power points
- Added extras such as neons, safety shutters and extra switches allow for even more versatility
- Safety shutters help prevent accidental contact with live terminals within the power point
- Option of included leakage and surge protection
Specifications
Design
| Range of product | Series 2000 |
|---|---|
| Product or component type | socket-outlet |
| Product brand | Clipsal |
| Surface finish | glossy |
Physical
| Quantity per set | set of 1 |
|---|---|
| Marking | without marking |
| Local signalling | without light indicator |
| Device mounting | flush |
| Fixing mode | by screws |
| [in] rated current | 10 A |
| [ue] rated operational voltage | 250 V AC |
| Depth | 31 mm |
| Length | 116 mm |
| Fixing center | 84 mm |
| Number of poles | 1 |
| Width | 76 mm |
| Standards |
|
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120506EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PVC (polyvinyl chloride) |
|---|
Documents & downloads
-
All
-
CAD Files and Packs
-
Product Brochures
-
Technical Data Catalogues
-
Certificates (MSDS)
-
Declaration of Conformity (Sustainability)
-
BIM Model
2010-BK EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
2010-BK EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
2010-BK REACh Regulation
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
2010-BK REACh Regulation
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
2010-CM EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
2010-CM EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
Range
The contemporary styling and flexibility of the 2000 Series and C2000 range have made it a popular range of switches and power points.
2000 Series and C2000 range offers a range of stylish switches in standard and architrave sizes. Power points are available in single, double and automatic models, in vertical or horizontal format, with options such as neons, extra switches and safety shutters. The extensive product range also includes dimmers, fan speed controllers, timers, weatherproof switches and TV, data and phone sockets.
