Easy UPS Tower 3kVA, 230V, 4x Australian outlets, Intelligent Card Slot, LCD

Home ProductsNetwork ConnectivityUPSTower

Easy UPS Tower 3kVA, 230V, 4x Australian outlets, Intelligent Card Slot, LCD

Item Number: SRVS3KI-AZ

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width190 mm

Height icon

Height336 mm

Depth icon

Depth425 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Easy UPS 1Ph On-Line

Product or component type

uninterruptible power supply (UPS)

Warranty

2 years repair or replace

Physical

Rated power in w

2400 W

Number of cables

1

Height

336 mm

Width

190 mm

Depth

425 mm

Net weight

26.8 kg

Mounting mode

not rack-mountable

Mounting position

vertical

Mounting mode

tower

Product certifications

CE

Standards

  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018

Ambient air temperature for operation

0...40 °C

Ambient air temperature for storage

-20...50 °C

Ip degree of protection

IP20

Relative humidity

0...95 % non-condensing

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Compliant

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant

China rohs regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Others

Life cycle assessment data

No

If one of the deliverables is not relevant please give the reason

Brand Labelled/ODM Products

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Legacy weee scope

In

Warranty duration(in months) bmecat

24

Weee label

N/A

Outside of Europe

Presentation

For small to medium businesses, Easy UPS 1 Ph On-Line provides essential power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments.

Lead time

Usually in Stock

Main input voltage

230 V AC 1 phase

Input voltage

  • 220 V
  • 240 V

Input voltage limits

  • 110...285 V half load
  • 160...280 V full load

Network frequency

40...70 Hz auto sensing

Output voltage

  • 220 V
  • 240 V

Rated power in va

3000 VA

Bypass type

internal bypass (automatic and manual)

Crest factor

3 : 1

Efficiency

88 % (full load)

Battery type

lead-acid internal included

Control panel

multifunction LCD status and control console

Free slots

1

Ups connectivity

  • serial port
  • USB port
  • available expansion slot

Cable length

1.48 m

Mounting location

front

Usb compatible

No

Graph display

1

Storage altitude

0...15000 m

Storage relative humidity

0...95 % non-condensing

Acoustic level

50 dBA

Operating altitude

0...3000 m

Battery type

lead-acid battery

Battery voltage

72 V

Battery life

3...5 year(s)

Battery design life

2 year(s)

Ups design life

3 year(s)

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

46.5 cm

Package 1 width

32.5 cm

Package 1 length

56.5 cm

Package 1 weight

29 kg

Sustainable packaging

No

Energy efficiency optimized

False

F-gas free

N/A

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

China rohs label

1

Take-back

No

Warranty (in months)

24
Show all specifications
