Back-UPS Pro APC Back-UPS Pro for Gaming 2200VA/1320W, Tower, 230V, 6x Australian outlets, RGB Lights, Pure Sine Wave, Arctic (White)

Home ProductsNetwork ConnectivityUPSAPC Back-UPS Pro for Gaming

Back-UPS Pro APC Back-UPS Pro for Gaming 2200VA/1320W, Tower, 230V, 6x Australian outlets, RGB Lights, Pure Sine Wave, Arctic (White)

Item Number: BGM2200-AZ

Datasheet

Product Dimensions

Width icon

Width104.14 mm

Height icon

Height292.1 mm

Depth icon

Depth408.94 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Back-UPS Pro

Product or component type

uninterruptible power supply (UPS)

Warranty

2 years repair or replace, 3 years repair or replace for European Union countries

Physical

Rated power in w

1320 W

Number of cables

1

Height

292.1 mm

Width

104.14 mm

Depth

408.94 mm

Net weight

12.5 kg

Mounting support

floor

Mounting mode

not rack-mountable

Mounting position

vertical

Mounting mode

tower

Product certifications

  • CE
  • CB

Ambient air temperature for operation

0...40 °C

Ambient air temperature for storage

-15...40 °C

Ip degree of protection

IP20

Relative humidity

0...95 %

Rohs exemption information

Yes

Environmental disclosure

ENVPEP1712010EN

Eu rohs directive

Compliant with Exemptions

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Reach regulation

Reference contains Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant By Exemption

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Life cycle assessment data

Yes

If one of the deliverables is not relevant please give the reason

ODM

Substance regulation data deliverable

Yes

Legacy weee scope

In

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Warranty duration(in months) bmecat

24

Lead time

Usually in Stock

Main input voltage

230 V AC 1 phase

Input voltage

230 V

Input protection type

circuit breaker

Switching current capacity

15 A

Plug standard

Australian

Input voltage limits

168...302 V

Network frequency

50/60 Hz +/- 3 Hz

Rated power in va

2200 VA

Type of usb power supply

USB type A + C

Battery type

lead-acid internal included

Control panel

multifunction LCD status and control console

Free slots

0

Alarm

alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Ups connectivity

USB port

Cable length

5 ft

Usb compatible

Yes

Additional specification

gaming performance

Graph display

1

Storage altitude

0...10000 ft

Storage relative humidity

0...95 %

Acoustic level

45 dBA

Operating altitude

0...10000 ft

Battery type

lead-acid battery

Battery voltage

24 V

Number of battery replacement quantity

1

Overcurrent protection

15 A

Battery life

3...5 year(s)

Battery design life

3 year(s)

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

15.5 cm

Package 1 width

35.5 cm

Package 1 length

48 cm

Package 1 weight

14.38 kg

Scc14

20731304634816

Green premium status for reporting

Green Premium product

Total lifecycle carbon footprint

512 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

137.78654545454546

Carbon footprint of the manufacturing phase [a1 to a3]

138 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

1.485061818181818

Carbon footprint of the distribution phase [a4]

1 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0

Carbon footprint of the installation phase [a5]

0 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

371.26545454545453

Carbon footprint of the use phase [b2, b3, b4, b6]

371 kg CO2 eq.

Sustainable packaging

No

Carbon footprint of the end-of-life phase [c1 to c4]

1.3098872727272728

Carbon footprint of the end-of-life phase [c1 to c4]

1 kg CO2 eq.

Energy efficiency optimized

Energy efficient product

F-gas free

N/A

Take-back

Yes

Product contributes to saved and avoided emissions

No

Removable battery

User replaceable

Total lifecycle carbon footprint

512.4509090909091

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

Energy efficiency optimized

Energy efficient product

End of life manual availability

ENVEOLI1712010_EN

Removable battery

User replaceable

Take-back

Yes

Warranty (in months)

24
