Specifications
Design
Product brand
Clipsal
Range of product
StarServe
Physical
Width
405 mm
Height
750 mm
Depth
150 mm
Device mounting
- flush
- surface
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Environmental disclosure
ENVPEP121018EN
Circularity profile
N/A
Material
Material
ABS (acrylonitrile butadiene-styrene): housing
Documents & downloads
hide showFilter items
-
All
-
Product Brochures
-
Environmental Disclosure
Frequently Asked Questions
What are the kind of Starserve enclosures are there?
Hide ShowPlease see the Following table for StarServe Enclosures:
Part Number | Description | Dimensions |
3105ABEN | Slimline Plastic Enclosure | 269mm(W) X 383mm(H) X 84mm(D) |
3105PEN7440 | ABS Plastic Enclosure - Suited for NBN | 405mm(W) X 750mm(H) X 150mm(D) |
8000LEN | Lite-Size Metal Enclosure | 200mm(W) X 300mm(H) X 145(D) |
8000LFK | 8000LEN Enclosure Flush Kit | |
3105PENF | Professional Metal Enclosure, Flush Mount | 465mm(W) X 895mm(H) X 113mm(D) |
8000MEN | Mid-Size Metal Enclosure | 415mm(W) 450mm(H) X 145mm(D) |
8000MENFK | 8000MEN Enclosure Flush Kit | |
3105PENS | Professional Metal Enclosure, Surface Mount | 465mm(W) X 895mm(H) X 113mm(D) |
For Further information please visit https://updates.clipsal.com/clipsalonline/files/brochures/d0000090.pdf
