Specifications
Design
Product brand
Clipsal
Range of product
Titanium
Product or component type
modular jack
Physical
Connector type
110 RJ45
Communication network category
5e
Fixing mode
special tool
Awg gauge
AWG 24...AWG 22
[in] rated current
1.5 A
Reach free of svhc
Yes
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP111057EN
Material
Material
phosphor bronze
Others
Package 1 bare product quantity
1
Number of ways
8 ways
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
0.016 kg
