Clipsal - Lighting Weatherproof Batten LED 600mm, IP65, CCT 3K/4K/6K, 20W

Item Number: CLITPWP1

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554812058	-

Specifications

Design

Range	Clipsal
Product or component type	batten light
Device application	lighting
Colour tint	grey/white

Physical

Type of installation	outdoor
[ue] rated operational voltage	240 V AC 50 Hz
Mounting mode	ceiling
Electrical insulation class	class I
Height	68 mm
Width	105 mm
Length	650 mm
Net weight	1.0 kg
Ip degree of protection	IP65
Ik degree of protection	IK08
Relative humidity	10...95 %
Ambient air temperature for operation	-10...45 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2409030_V1
Eu rohs directive	Compliant By Exemption

Others

Average percentage of recycled plastic content	0 %
Package 1 bare product quantity	1
Legacy weee scope	In
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Product name	TPWP Series
Operational power in w	20 W
Colour rendering index	R_a=80
Luminous flux	2000 lm
Bulb lifespan	30000 h
Colour temperature	3000 K 4000 K 6500 K
Light source	LED
Shape	rectangular
Targeted country	Australia
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	7.4 cm
Package 1 width	10.8 cm
Package 1 length	69.0 cm
Package 1 weight	1.2 kg
Unit type of package 2	BB1
Number of units in package 2	6
Package 2 height	17.0 cm
Package 2 width	34.5 cm
Package 2 length	71.5 cm
Package 2 weight	7.0 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	122 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	1.4465318888815766
Carbon footprint of the manufacturing phase [a1 to a3]	1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.028175621905979744
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.0011601600182369481
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	119.63256626053085
Carbon footprint of the use phase [b2, b3, b4, b6]	120 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.4138411713793967
Carbon footprint of the end-of-life phase [c1 to c4]	0.4 kg CO2 eq.
Pvc free	No
Silicone-free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	121.52227510271605
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
Silicone-free	No
End of life manual availability	ENVEOLI2409030EN
Take-back	No
Warranty (in months)	18
