Datasheet
Product Dimensions
Width357 mm
Heightbody with trunnion arm: 260 mm
Depth45 mm
Close
Specifications
Design
| Range | Clipsal |
|---|---|
| Product or component type | floodlight |
| Device application | lighting |
| Warranty | 3-Years |
Physical
| Type of installation | outdoor |
|---|---|
| Device mounting | surface |
| [ue] rated operational voltage | 240 V AC 50 Hz |
| Electrical insulation class | class I |
| Height | body with trunnion arm: 260 mm |
| Width | 357 mm |
| Depth | 45 mm |
| Net weight | 2.45 kg |
| Ip degree of protection | IP65 |
| Ambient air temperature for operation | -10...40 °C |
| Relative humidity | 10...95 % non-condensing |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2305021EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
