Clipsal - Lighting Downlight 750lm, recessed low glare, white

Item Number: CLITPDLLG

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width103 mm

Height86 mm

Depth86 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606487149378	-

Specifications

Design

Range	Clipsal
Product or component type	downlight
Market segment	residential
Colour tint	white
Warranty	3 Years

Physical

Device mounting	ceiling
Rated power in w	7 W
[ue] rated operational voltage	230/240 V AC 50 Hz
Width	103 mm
Height	86 mm
Depth	86 mm
Net weight	190 g
Ip degree of protection	IP44
Ik degree of protection	IK02
Reach free of svhc	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2305020_V1
Reach regulation	Free of Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Others

Package 2 bare product quantity	20
Package 3 bare product quantity	640
Package 1 bare product quantity	1
Legacy weee scope	In
Warranty duration(in months) bmecat	36
Weee label	N/A
Weee applicability	Finished product
Average percentage of recycled plastic content	0 %
	Outside of Europe
Main colour tint	white
Light source	LED
Luminous flux	800 lm 3000 K 800 lm 4000 K 800 lm 6000 K
Colour rendering index	R_a=80
Bulb lifespan	35000 h
Beam angle	60 °
Cut-out dimensions	90 mm
Targeted country	Australia
Insulation contact rating	IC-4
Unified glare rating	< 22
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	10 cm
Package 1 width	11 cm
Package 1 length	11 cm
Package 1 weight	283 g
Unit type of package 2	CAR
Number of units in package 2	20
Package 2 height	23.3 cm
Package 2 width	24.2 cm
Package 2 length	57.9 cm
Package 2 weight	6.141 kg
Unit type of package 3	PAL
Number of units in package 3	640
Package 3 height	110 cm
Package 3 width	114 cm
Package 3 length	114 cm
Package 3 weight	210.512 kg
Total lifecycle carbon footprint	320 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	2.0842615774365916
Carbon footprint of the manufacturing phase [a1 to a3]	2 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.08123293827887187
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.1733103923741804
Carbon footprint of the installation phase [a5]	0.2 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	317.5
Carbon footprint of the use phase [b2, b3, b4, b6]	318 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.4705052876753466
Carbon footprint of the end-of-life phase [c1 to c4]	0.5 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	320.30931019576497
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	ENVEOLI2305020_V1
Take-back	No
Warranty (in months)	36
