Home ProductsLightingClipsal - LightingBatten weatherproof LED

Clipsal - Lighting Batten weatherproof LED 6W, IP54, black

Item Number: CLITPBH

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width196 mm

Height196 mm

Depth58 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606487344780	-
4	CAR	13606487344787	-

Specifications

Design

Range	Clipsal
Product or component type	batten light
Device application	lighting
Colour tint	black

Physical

Type of installation	outdoor
[ue] rated operational voltage	230...240 V AC 50 Hz
Mounting mode	ceiling
Electrical insulation class	class II
Height	196 mm
Width	196 mm
Depth	58 mm
Ip degree of protection	IP57
Ik degree of protection	IK08
Relative humidity	10...95 %
Ambient air temperature for operation	-10...45 °C
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2502027_V1
Eu rohs directive	Compliant

Others

Package 1 bare product quantity	1
Package 2 bare product quantity	4
Legacy weee scope	In
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Package 3 bare product quantity	144
Average percentage of recycled plastic content	0 %
	Outside of Europe
Product name	TPWP Series
Colour rendering index	R_a=80
Luminous flux	600 lm
Bulb lifespan	50000 h
Colour temperature	3000 K 4000 K 5700 K
Light source	LED
Shape	round
Main colour tint	black
Targeted country	Australia
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	19.5 cm
Package 1 width	15 cm
Package 1 length	19 cm
Package 1 weight	1.045 kg
Unit type of package 2	CAR
Number of units in package 2	4
Package 2 height	21.3 cm
Package 2 width	31.9 cm
Package 2 length	39.9 cm
Package 2 weight	4.639 kg
Unit type of package 3	PAL
Number of units in package 3	144
Package 3 height	102 cm
Package 3 width	114 cm
Package 3 length	114 cm
Package 3 weight	199 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	342 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	7.49052041198655
Carbon footprint of the manufacturing phase [a1 to a3]	7 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0657221537762251
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.00927285483885174
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	333.5630656560366
Carbon footprint of the use phase [b2, b3, b4, b6]	334 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.3737756355971297
Carbon footprint of the end-of-life phase [c1 to c4]	0.4 kg CO2 eq.
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	341.5023567122354
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
End of life manual availability	ENVEOLI2502027EN
Take-back	No
Warranty (in months)	18
