Datasheet
Close
Specifications
Design
| Range | Clipsal |
|---|---|
| Product or component type | batten light |
| Device application | lighting |
| Colour | white |
Physical
| Type of installation | indoor/outdoor |
|---|---|
| [ue] rated operational voltage | 240 V AC 50 Hz |
| Control type | test button |
| Supply | non-maintained |
| Device mounting | surface |
| Mounting mode | ceiling |
| Ip degree of protection | IP20 |
| Electrical insulation class | class I |
| Length | 1170 mm |
| Width | 72.5 mm |
| Height | 72 mm |
| Net weight | 2.2 kg |
| Ambient air temperature for operation | -10...45 °C |
| Relative humidity | 10...95 % |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2502027EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | X |
| Eu rohs directive | Compliant By Exemption |
Documents & downloads
Filter items
-
All
-
Declaration of Conformity (Sustainability)
