Clipsal - Lighting Batten Diffused LED 1200mm

Item Number: CLITPDB2

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554812096	-

Specifications

Design

Range	Clipsal
Product or component type	batten light
Device application	lighting
Colour tint	white

Physical

Type of installation	indoor/outdoor
[ue] rated operational voltage	240 V AC 50 Hz
Mounting mode	ceiling
Ip degree of protection	IP20
Electrical insulation class	class I
Length	1170 mm
Width	72 mm
Height	72.5 mm
Net weight	1.8 kg
Ambient air temperature for operation	-10...45 °C
Relative humidity	10...95 %
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2502027EN
Eu rohs directive	Compliant By Exemption

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Weee label	N/A
Weee applicability	Finished product
Product name	TPDB Series
Operational power in w	40 W
Light source	LED
Luminous flux	4000 lm
Bulb lifespan	30000 h
Colour temperature	4000 K
Shape	rectangular
Colour rendering index	R_a=80
Targeted country	Australia
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	7.5 cm
Package 1 width	7.7 cm
Package 1 length	121.6 cm
Package 1 weight	2.0 kg
Unit type of package 2	BB1
Number of units in package 2	4
Package 2 height	17.0 cm
Package 2 width	17.4 cm
Package 2 length	123.0 cm
Package 2 weight	8.3 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	17 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	10.0758089287753
Carbon footprint of the manufacturing phase [a1 to a3]	10 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.558567230286276
Carbon footprint of the distribution phase [a4]	0.6 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.778359666250766
Carbon footprint of the installation phase [a5]	0.8 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.34718
Carbon footprint of the use phase [b2, b3, b4, b6]	0.3 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	4.93770879419204
Carbon footprint of the end-of-life phase [c1 to c4]	5 kg CO2 eq.
Pvc free	No
Silicone-free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	16.6976246195044
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
Silicone-free	No
End of life manual availability	ENVEOLI2502027EN
Take-back	No
Warranty (in months)	18

Show all specifications

Documents & downloads

All
End of Life Manual
Environmental Disclosure
Declaration of Conformity (Sustainability)

Important: Some software files may need a mySchneider or Club login to download.

ZIP

Clipsal - Lighting Batten Weatherproof LED, 1200mm, Colour Changing, Power Shifting

VERSION

1.0

DATE

28 Oct 2025

REVISION

1.0

DOWNLOAD (ZIP) 339.1 KB

ZIP

Clipsal - Lighting Batten Weatherproof LED, 1200mm, Colour Changing, Power Shifting

VERSION

1.0

DATE

28 Oct 2025

REVISION

1.0

DOWNLOAD (ZIP) 301.6 KB

ZIP

CLITPDB2 EU RoHS Directive

VERSION

1.0

DATE

01 Jan 1900

REVISION

1.0

ZIP

CLITPDB2 EU RoHS Directive

VERSION

1.0

DATE

01 Jan 1900

REVISION

1.0

ZIP

CLITPDB2 REACh Regulation

VERSION

1.0

DATE

01 Jan 1900

REVISION

1.0

ZIP

CLITPDB2 REACh Regulation

VERSION

1.0

DATE

01 Jan 1900

REVISION

1.0
