Thalassa, PLS box, polyester rear, transparent PC cover IP66 27x36x18cm

Thalassa, PLS box, polyester rear, transparent PC cover IP66 27x36x18cm

Item Number: NSYPLS2736G

Thalassa PLS box polyester rear with transparent PC cover. 270 x 360 x 180 mm. Insulating modular box. One piece moulded body. Wall mounted. High transparent cover, cover locking screw removable. Polyester reinforced with fibreglass rear, polycarbonate cover. Grey RAL 7035. IP65, IK09, NEMA (13,4X) 960°C fire resistance. Insulation Class II.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Thalassa

Device application

multi-purpose

Product or component type

insulating modular box

Colour

body: grey (RAL 7035)

Physical

Standards

NEMA classification 13|IEC 62208|NEMA 4X

Product certifications

UL

Electrical insulation class

class II

Ip degree of protection

IP66 conforming to IEC 60529

Ik degree of protection

IK09 conforming to IEC 62262

Ambient air temperature for storage

-30...70 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury free

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Rohs exemption information

Yes

Environmental disclosure

ENVPEP110704EN

Circularity profile

N/A

Material

Device composition

1 cover: on enclosure|1 rear part: on enclosure| locking screws

Material

cover: polycarbonate|rear: polyester reinforced with fibreglass

Others

Package 1 bare product quantity

1

Package 2 bare product quantity

90

Product name

Thalassa PLS

Device short name

PLS

Enclosure nominal height

270 mm

Enclosure nominal width

360 mm

Enclosure nominal depth

180 mm

Enclosure mounting

wall mounted

Body type

one piece moulded

Type of front cover

low transparent cover

Lock type

slot screw

Removable parts

cover locking screw

Fire resistance

960 °C conforming to IEC 62208

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

19.000 cm

Package 1 width

29.000 cm

Package 1 length

38.000 cm

Package 1 weight

2.080 kg

Unit type of package 2

PAM

Number of units in package 2

90

Package 2 height

186.000 cm

Package 2 width

100.000 cm

Package 2 length

120.000 cm

Package 2 weight

200.430 kg

Scip number

a18cb304-12b9-4d34-8ea6-7f2f757726a8

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A
