Thalassa, DLP modular dist chassis, 297modules(18mm) insulating material for PLA H1500xW750

Item Number: NSYDLP297G

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Thalassa

Device application

multi-purpose|modular distribution application

Product or component type

chassis

Colour

front panel: grey (RAL 7035)

Sustainable offer status

Green Premium product

Physical

Range compatibility

Thalassa Thalassa PLA|Thalassa Thalassa PHD

Fixing mode

by fixing element - on front with supports location

Height

1500 mm

Width

750 mm

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP110923EN

Circularity profile

N/A

Material

Device composition

1 chassis structure|1 neutral/earth strip 2 x 16 mm² 5 x 6 mm²|9 front panels with 35 mm DIN rail

Material

front panel: self-extinguishing|chassis structure and rails: galvanised steel

Others

Package 1 bare product quantity

1

Accessory / separate part category

mounting accessory

Device short name

DLP

Enclosure nominal dimensions

-

Mounting location

front of enclosure

Additional information

IP2x not respected when chassis is mounted at 67 mm

Adjustment

in height from 40 to 85 mm for DIN rail

Number of horizontal rows

9

Total number of 18 mm modules

297

Type of front plate

cut-out plate

Number of cut-out

9 cut-outs

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

14.000 cm

Package 1 width

67.000 cm

Package 1 length

143.000 cm

Package 1 weight

12.520 kg

Unit type of package 2

P2M

Number of units in package 2

4

Package 2 height

90.000 cm

Package 2 width

200.000 cm

Package 2 length

120.000 cm

Package 2 weight

65.080 kg
