TeSys K Control Relay 1 NO + 1 NC, <= 690 V, 12V DC standard coil
Item Number: CA3SK11JD
Specifications
Design
Range of product
Range
Product or component type
Warranty
Physical
[ue] rated operational voltage
Mounting support
- rail
- plate
Connections - terminals
- screw clamp terminals 1 cable(s) 1.5-6 mm²solid
- screw clamp terminals 2 cable(s) 1.5-4 mm²solid
- screw clamp terminals 1 cable(s) 0.5-6 mm²flexible without cable end
- screw clamp terminals 1 cable(s) 0.35-6 mm²flexible with cable end
- screw clamp terminals 2 cable(s) 0.35-1.5 mm²flexible with cable end
- screw clamp terminals 2 cable(s) 0.35-2.5 mm²flexible without cable end
Mechanical durability
Height
Width
Depth
Net weight
Standards
- EN/IEC 60947-5-1
- UL 60947-5-1
- CSA C22.2 No 60947-5-1
Product certifications
- CB Scheme
- cULus
- EAC
- CE
- UKCA
Ip degree of protection
Ambient air temperature for operation
Ambient air temperature for storage
Mercury free
Rohs exemption information
Eu rohs directive
China rohs regulation
Others
Legacy weee scope
Package 1 bare product quantity
Weee label
Product name
Device short name
Contactor application
Utilisation category
- DC-13
- AC-15
Pole contact composition
Control circuit type
[uc] control circuit voltage
[ith] conventional free air thermal current
Associated fuse rating
- 10 A gL conforming to VDE 0660
- 10 A gL conforming to IEC 60947
[ui] rated insulation voltage
- 690 V conforming to IEC 60947
- 690 V conforming to VDE 0110 group C
- 690 V conforming to BS 5424
- 690 V conforming to UL 508
- 690 V conforming to CSA C22.2 No 14
Tightening torque
Control circuit voltage limits
- operational: 0.85...1.1 Uc (at <50 °C)
- drop-out: 0.1...0.75 Uc (at <50 °C)
Operating time
- 4...6 ms coil de-energisation and NO opening
- 8...12 ms coil energisation and NO closing
- 6...8 ms coil de-energisation and NC closing
- 10...18 ms coil energisation and NC opening
Maximum operating rate
Inrush power in w
Hold-in power consumption in w
Heat dissipation
Compatibility code
Protective treatment
Operating altitude
Unit type of package 1
Number of units in package 1
Package 1 height
Package 1 width
Package 1 length
Package 1 weight
Sustainable packaging
Weee label
Warranty (in months)
