TeSys-LADN11-ADD ON BLOCK 1 NO + 1 NC D-Model

TeSys D - auxiliary contact block - 1 NO + 1 NC - screw-clamps terminals

Home ProductsIndustrialTeSysAuxiliary contact block, TeSys Deca, 1NO + 1NC, front mounting, screw clamp terminals

TeSys D, Auxiliary contact block, TeSys Deca, 1NO + 1NC, front mounting, screw clamp terminals

Item Number: LADN11

[NO COLOUR] 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	CAR	3389110383836	-
10	PAC	53389110383831	-

Specifications

Design

Range

TeSys|TeSys Deca

Range of product

TeSys Deca

Product or component type

auxiliary contact block

Sustainable offer status

Green Premium product

Physical

Range compatibility

[ue] rated operational voltage

690 V AC 25...400 Hz

[ie] rated operational current

6 A at 120 V AC-15|1.04 A at 690 V AC-15|0.55 A at 125 V DC-13|0.1 A at 600 V DC-13

Standards

EN/IEC 60947-5-1|UL 60947-5-1|CSA C22.2 No 60947-5-1|GB/T 14048.5

Product certifications

CB|UL|CSA|CCC|EAC|UKCA

Protection type

gG fuse 10 A

Mechanical durability

30 Mcycles

Insulation resistance

> 10 MOhm

Connections - terminals

screw clamp terminals 1 cable(s) 1-4 mm²flexible with cable end|screw clamp terminals 1 cable(s) 1-4 mm²flexible without cable end|screw clamp terminals 2 cable(s) 1-2.5 mm²flexible with cable end|screw clamp terminals 2 cable(s) 1-4 mm²flexible without cable end|screw clamp terminals 1 cable(s) 1-4 mm²rigid without cable end|screw clamp terminals 2 cable(s) 1-4 mm²rigid without cable end

Height

48 mm

Width

26 mm

Depth

42 mm

Environmental characteristic

normal environment

Ip degree of protection

IP20 conforming to IEC 60529

Ambient air temperature for storage

-60...80 °C

Ambient air temperature for operation

-5...60 °C

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP110807EN_V2

Others

Package 1 bare product quantity

Product name

TeSys Deca

Device short name

LADN

Mounting location

front

Pole contact composition

1 NO + 1 NC

Auxiliary contacts operation

instantaneous

[ui] rated insulation voltage

690 V conforming to IEC 60947-5-1|600 V conforming to UL|600 V conforming to CSA

[ith] conventional free air thermal current

10 A (at 60 °C)

Irms rated making capacity

140 A AC conforming to IEC 60947-5-1|250 A DC conforming to IEC 60947-5-1

Permissible short-time rating

100 A 60 °C 1 s|120 A 60 °C 500 ms|140 A 60 °C 100 ms

Minimum switching current

5 mA

Minimum switching voltage

17 V

Non-overlap time

1.5 ms on de-energisation no overlap between NC and NO contact|1.5 ms on energisation no overlap between NC and NO contact

Tightening torque

1.7 N.m - with screwdriver flat Ø 6 mm|1.7 N.m - with screwdriver Philips No 2|1.7 N.m - with screwdriver pozidriv No 2

Shielding continuity terminal

without

Protective treatment

TH conforming to IEC 60068

Operating altitude

3000 m

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

3.000 cm

Package 1 width

4.200 cm

Package 1 length

5.300 cm

Package 1 weight

34.000 g

Unit type of package 2

BB1

Number of units in package 2

Package 2 height

3.000 cm

Package 2 width

8.800 cm

Package 2 length

25.600 cm

Package 2 weight

348.000 g

Unit type of package 3

S03

Number of units in package 3

320

Package 3 height

30.000 cm

Package 3 width

30.000 cm

Package 3 length

40.000 cm

Package 3 weight

11.486 kg

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
