Home ProductsIndustrialSpacial S3XWall mounted enclosure

Spacial S3X Wall mounted enclosure stainless steel 304L,double plain door, 1200x1000x300mm, IP55

Item Number: NSYS3X121030

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480154997	-

Specifications

Design

Range	Spacial
Device application	multi-purpose
Product or component type	compact enclosure
Surface finish	body and door: Scotch-Brite® brushed
Warranty	18 months

Physical

Net weight	51.8 kg
Standards	IEC 62208 UL cUL
Product certifications	CAN/CSA 22 UL 508 type A
Ip degree of protection	IP55 conforming to IEC 60529
Ik degree of protection	IK10 conforming to IEC 62262
Environmental characteristic	specific hygiene corrosive
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2109018EN
Eu rohs directive	Compliant
California proposition 65	WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Material

Device composition	1 body 2 door 1 lock: door 1 reinforcement frame drilled: door
Material	body and door: stainless steel 304L hinge: stainless steel

Others

Average percentage of recycled plastic content	0 %
Package 2 bare product quantity	3
Package 1 bare product quantity	1
Legacy weee scope	Out
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	No
Product name	Spacial S3X
Enclosure nominal height	1200 mm
Enclosure nominal width	1000 mm
Enclosure nominal depth	300 mm
Installation accessory type	wall-mounting
Body type	single piece body, cross-shaped structure gutter shaped front rail
Door type	plain
Number of doors	front face: 2 door(s)
Door opening side	reversible (120 °)
Lock type	3 points lock, 3 mm double-bar
Mounting plate description	without mounting plate
Type of gland plate	without gland plate
Accessibility for operation	front
Removable parts	door by hinges
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	32.000 cm
Package 1 width	101.000 cm
Package 1 length	122.000 cm
Package 1 weight	51.800 kg
Unit type of package 2	PAL
Number of units in package 2	3
Package 2 height	117.000 cm
Package 2 width	100.000 cm
Package 2 length	122.000 cm
Package 2 weight	179.400 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	770 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	528.6346710649485
Carbon footprint of the manufacturing phase [a1 to a3]	529 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	102.8397150111744
Carbon footprint of the distribution phase [a4]	103 kg CO2 eq.
Carbon footprint of the installation phase [a5]	2.5712493122784417
Carbon footprint of the installation phase [a5]	3 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	135.97661963898636
Carbon footprint of the end-of-life phase [c1 to c4]	136 kg CO2 eq.
Pvc free	Yes
Silicone-free	Yes
Energy efficiency optimized	False
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	770.0222550273878
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Scip number	e893f0a0-d2cc-4011-9425-3873dde70142
Pvc free	Yes
Silicone-free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
